NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MJI)
PART NAME DESCRIPTION
POS.NO.
COMPO IN J622 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
COMPO IN JK61 90M-YT003980R 90M-YT003980R TERMINAL RCA-902AA-16 CJJ4L007Z
COMPO IN JK62 90M-YJ002680R 90M-YJ002680R OPT. CONNECTOR TORX179L HJSTORX179L
COMPO IN JK63 90M-YJ002680R 90M-YJ002680R OPT. CONNECTOR TORX179L HJSTORX179L
COMPO IN JK64 90M-YJ002670R 90M-YJ002670R OPT. CONNECTOR TOTX179L HJSTOTX179L
COMPO IN JK65 90M-YT003290R 90M-YT003290R TERMINAL B/B/B , N-PLATE CJJ4S018Z
COMPO IN R601 nsp nsp RESISTOR 75 OHM 1/5W J CRD20TJ750T
COMPO IN R602 nsp nsp RESISTOR 75 OHM 1/5W J CRD20TJ750T
COMPO IN R603 nsp nsp RESISTOR 75 OHM 1/5W J CRD20TJ750T
COMPO IN R604 nsp nsp RESISTOR 75 OHM 1/5W J CRD20TJ750T
COMPO IN R605 nsp nsp RESISTOR 75 OHM 1/5W J CRD20TJ750T
COMPO IN R606 nsp nsp RESISTOR 75 OHM 1/5W J CRD20TJ750T
COMPO IN R607 nsp nsp RESISTOR 75 OHM 1/5W J CRD20TJ750T
COMPO IN R608 nsp nsp RESISTOR 75 OHM 1/5W J CRD20TJ750T
COMPO IN R609 nsp nsp RESISTOR 75 OHM 1/5W J CRD20TJ750T
COMPO IN R610 nsp nsp RESISTOR 4.7 OHM 1/5W J CRD20TJ4R7T
COMPO IN R611 nsp nsp RESISTOR 4.7 OHM 1/5W J CRD20TJ4R7T
COMPO IN R630 nsp nsp RESISTOR 10K OHM 1/5W J CRD20TJ103T
COMPO IN R631 nsp nsp RESISTOR 10K OHM 1/5W J CRD20TJ103T
COMPO IN R632 nsp nsp RESISTOR 75 OHM 1/5W J CRD20TJ750T
COMPO IN R633 nsp nsp RESISTOR 75 OHM 1/5W J CRD20TJ750T
COMPO IN R634 nsp nsp RESISTOR 75 OHM 1/5W J CRD20TJ750T
COMPO IN R635 nsp nsp RESISTOR 75 OHM 1/5W J CRD20TJ750T
COMPO IN R636 nsp nsp RESISTOR 100 OHM 1/5W J CRD20TJ101T
COMPO IN R637 nsp nsp RESISTOR 1 OHM 1/5W J CRD20TJ1R0T
COMPO IN R638 nsp nsp RESISTOR 1 OHM 1/5W J CRD20TJ1R0T
COMPO IN R639 nsp nsp RESISTOR 1 OHM 1/5W J CRD20TJ1R0T
COMPO IN R640 nsp nsp RESISTOR 1 OHM 1/5W J CRD20TJ1R0T
COMPO IN R641 nsp nsp RESISTOR 100K OHM 1/5W J CRD20TJ104T
COMPO IN R642 nsp nsp RESISTOR 100K OHM 1/5W J CRD20TJ104T
COMPO IN R643 nsp nsp RESISTOR 1K OHM 1/5W J CRD20TJ102T
COMPO IN R644 nsp nsp RESISTOR 1K OHM 1/5W J CRD20TJ102T
COMPO IN R645 nsp nsp RESISTOR 4.7K OHM 1/5W J CRD20TJ472T
COMPO IN R646 nsp nsp RESISTOR 4.7K OHM 1/5W J CRD20TJ472T
ENCORDER PCB (CUP11693-2)
ENCORDER C841 nsp nsp CERAMIC CAP. 100PF 50V K HCBS1H101KBT
ENCORDER C871 nsp nsp CERAMIC CAP. 100PF 50V K HCBS1H101KBT
ENCORDER C872 nsp nsp CERAMIC CAP. 100PF 50V K HCBS1H101KBT
ENCORDER C873 nsp nsp CERAMIC CAP. 100PF 50V K HCBS1H101KBT
ENCORDER CN86 90M-YJ002790R 90M-YJ002790R JACK 7P KJP07GB144ZP
ENCORDER D801 90M-HI101040R 90M-HI101040R L.E.D. SLR342VCTB7T089 HVD342VCTB7T089
ENCORDER EN82 90M-SR000270R 90M-SR000270R ROTARY SWITCH EC16B12S0AD4ZZZ HSR2A032Z
ENCORDER J549 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
ENCORDER J551 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
ENCORDER J552 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
ENCORDER J574 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
ENCORDER J582 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
ENCORDER J604 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
ENCORDER J801 /L1G nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
ENCORDER J801 /U1B nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
ENCORDER J801 /U1S nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
ENCORDER J802 /L1G nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
ENCORDER J802 /U1B nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
ENCORDER J802 /U1S nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
ENCORDER Q802 00MBA10004000 00MBA10004000 TRANSISTOR KRA111M HVTKRA111MT
ENCORDER R871 nsp nsp RESISTOR 10K OHM 1/5W J CRD20TJ103T
ENCORDER R872 nsp nsp RESISTOR 10K OHM 1/5W J CRD20TJ103T
ENCORDER R873 nsp nsp RESISTOR 10K OHM 1/5W J CRD20TJ103T
ENCORDER R874 nsp nsp RESISTOR 10K OHM 1/5W J CRD20TJ103T
ENCORDER R875 nsp nsp RESISTOR 680 OHM 1/5W J CRD20TJ681T
ENCORDER R876 nsp nsp RESISTOR 820 OHM 1/5W J CRD20TJ821T
ENCORDER R877 nsp nsp RESISTOR 560 OHM 1/5W J CRD20TJ561T
ENCORDER R878 nsp nsp RESISTOR 680 OHM 1/5W J CRD20TJ681T
