Marantz SR4500 - Cup11693

61
NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MJI)
PART NAME DESCRIPTION
POS.NO.
ENCORDER SW94 90M-SP001210R 90M-SP001210R SWITCH 00802-0005 CST1A012ZT
ENCORDER SW95 90M-SP001210R 90M-SP001210R SWITCH 00802-0005 CST1A012ZT
FRONT PCB (CUP11693-1)
FRONT BN14 nsp nsp CONNECTIVE CORD CWB1B907230EN
FRONT BN86 90M-YP100220R 90M-YP100220R JACK KJP07GB145ZP
FRONT C801 nsp 00MOA47601640 ELECT CAP. 47UF 16V ZF CCEA1CH470T
FRONT C802 nsp 00MOA10601620 ELECT CAP. 10UF 16V ZF CCEA1CH100T
FRONT C804 nsp nsp CERAMIC CAP. 0.01UF 50V Z HCBS1H103ZFT
FRONT C805 nsp nsp CERAMIC CAP. 100PF 50V K HCBS1H101KBT
FRONT C806 nsp 00MOA10705020 ELECT CAP. 100UF 50V ZF CCEA1HH101T
FRONT C807 nsp nsp CERAMIC CAP. 100PF 50V K HCBS1H101KBT
FRONT C809 nsp nsp CERAMIC CAP. 100PF 50V K HCBS1H101KBT
FRONT C810 nsp nsp CERAMIC CAP. 100PF 50V K HCBS1H101KBT
FRONT C811 nsp nsp CERAMIC CAP. 100PF 50V K HCBS1H101KBT
FRONT C812 nsp nsp CERAMIC CAP. 0.1UF 50V Z HCBS1H104ZFT
FRONT C813 nsp 00MOA10701020 ELECT CAP. 100UF 10V ZF CCEA1AH101T
FRONT C814 nsp nsp CERAMIC CAP. 100PF 50V K HCBS1H101KBT
FRONT C815 nsp nsp CERAMIC CAP. 100PF 50V K HCBS1H101KBT
FRONT C816 nsp nsp CERAMIC CAP. 100PF 50V K HCBS1H101KBT
FRONT C817 nsp nsp CERAMIC CAP. 100PF 50V K HCBS1H101KBT
FRONT C818 nsp nsp CERAMIC CAP. 100PF 50V K HCBS1H101KBT
FRONT C820 nsp nsp CERAMIC CAP. 100PF 50V K HCBS1H101KBT
FRONT C821 nsp 00MOA10605020 ELECT CAP. 10UF 50V ZF CCEA1HH100T
FRONT C822 nsp nsp CERAMIC CAP. 100PF 50V K HCBS1H101KBT
FRONT C824 nsp nsp CERAMIC CAP. 0.1UF 50V Z HCBS1H104ZFT
FRONT C825 nsp nsp CERAMIC CAP. 390PF 50V K HCBS1H391KBT
FRONT C826 nsp nsp CERAMIC CAP. 100PF 50V K HCBS1H101KBT
FRONT C827 nsp nsp CERAMIC CAP. 100PF 50V KB CCKT1H101KB
FRONT C828 nsp 00MOA47601640 ELECT CAP. 47UF 16V ZF CCEA1CH470T
FRONT CN83 nsp nsp JACK CJP15GA117ZY
FRONT EN81 90M-SR000240R 90M-SR000240R ROTARY SWITCH EC16B243040HB HSR2A004Z
FRONT FIP1 90M-HQ300620R 90M-HQ300620R DISPLAY 16-BT-110GNK HFL16BT110GNK
FRONT IC81 00MHC10220090 00MHC10220090 IC HVINJU3430F
FRONT J803 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J804 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J805 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J806 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J807 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J809 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J810 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J811 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J812 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J813 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J814 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J815 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J816 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J817 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J818 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J821 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J822 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J823 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J824 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J825 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J826 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J827 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J828 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J841 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J842 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J843 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J844 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J845 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J846 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
FRONT J851 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
