Marantz SR4500 - Page 36

50
NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B
NAME
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MJI)
PART NAME DESCRIPTION
POS.NO.
CB15 /A1B nsp 90M-YU001570R FPC CARD , CABLE PITCH 1.25 CWC1C4A17B080B
CB15 /A1S nsp 90M-YU001570R FPC CARD , CABLE PITCH 1.25 CWC1C4A17B080B
CB15 /F1N nsp 90M-YU001260R FPC CARD , CABLE HTS-3000 CWC1C4A15B080B
CB15 /K1G nsp 90M-YU001260R FPC CARD , CABLE HTS-3000 CWC1C4A15B080B
CB15 /L1G nsp 90M-YU001260R FPC CARD , CABLE HTS-3000 CWC1C4A15B080B
CB15 /N1B nsp 90M-YU001570R FPC CARD , CABLE PITCH 1.25 CWC1C4A17B080B
CB15 /N1G nsp 90M-YU001570R FPC CARD , CABLE PITCH 1.25 CWC1C4A17B080B
CB15 /N1S nsp 90M-YU001570R FPC CARD , CABLE PITCH 1.25 CWC1C4A17B080B
CB15 /U1B nsp 90M-YU001260R FPC CARD , CABLE HTS-3000 CWC1C4A15B080B
CB15 /U1S nsp 90M-YU001260R FPC CARD , CABLE HTS-3000 CWC1C4A15B080B
CB27 nsp 90M-YU001690R FPC CARD , CABLE CWC1C4A27B110B
CB80 nsp 90M-YU001670R FPC CARD , CABLE CWC1B2A15A200B
CB83 nsp 90M-YU001680R FPC CARD , CABLE CWC1B2A15A220B
BN91 /A1B nsp nsp CONNECTIVE CODE WIRE ASS'Y CWZSR5400BN92
BN91 /A1S nsp nsp CONNECTIVE CODE WIRE ASS'Y CWZSR5400BN92
BN91 /N1B nsp nsp CONNECTIVE CODE WIRE ASS'Y CWZSR5400BN92
BN91 /N1G nsp nsp CONNECTIVE CODE WIRE ASS'Y CWZSR5400BN92
BN91 /N1S nsp nsp CONNECTIVE CODE WIRE ASS'Y CWZSR5400BN92
F901 /A1B nsp 90M-FS001200R FUSE FUSE KBA2C4000TLEZ
F901 /A1S nsp 90M-FS001200R FUSE FUSE KBA2C4000TLEZ
F901 /F1N nsp 90M-FS001190R FUSE FUSE KBA2C6300TLUZ
F901 /K1G nsp 90M-FS001200R FUSE FUSE KBA2C4000TLEZ
F901 /L1G nsp 90M-FS001190R FUSE FUSE KBA2C6300TLUZ
F901 /N1B 90M-FS001200R 90M-FS001200R FUSE FUSE KBA2C4000TLEZ
F901 /N1G 90M-FS001200R 90M-FS001200R FUSE FUSE KBA2C4000TLEZ
F901 /N1S 90M-FS001200R 90M-FS001200R FUSE FUSE KBA2C4000TLEZ
F901 /U1B nsp 90M-FS001190R FUSE FUSE KBA2C6300TLUZ
F901 /U1S nsp 90M-FS001190R FUSE FUSE KBA2C6300TLUZ
90M-FC500030R 90M-FC500030R FERRITE CORE FERRITE , RING 29X7.7X19 CLZ9W003Z
90M-FC500040R 90M-FC500040R FERRITE CORE FERRITE CORE(21.2X6.4X12.7) K5C T CLZ9Z028Z
nsp nsp PCB ASSY BIAS T.R PCB ASS'Y COP11696B
PACKING
/A1B nsp 00M07BW851270 USER GUIDE MANUAL , INSTRUCTION SR4500/ CQX1A942Z
/A1S nsp 00M07BW851270 USER GUIDE MANUAL , INSTRUCTION SR4500/ CQX1A942Z
/F1N nsp 00M07BW851110 USER GUIDE MANUAL , INSTRUCTION SR4500/F CQX1A944Z
/K1G nsp 00M07BW851350 USER GUIDE MANUAL , INSTRUCTION SR4500/ CQX1A943Z
/L1G nsp 00M07BW851350 USER GUIDE MANUAL , INSTRUCTION SR4500/ CQX1A943Z
/N1B 00M07BW851310 00M07BW851310 USER GUIDE MANUAL , INSTRUCTION SR4500/N CQX1A917Z
/N1G 00M07BW851310 00M07BW851310 USER GUIDE MANUAL , INSTRUCTION SR4500/N CQX1A917Z
/N1S 00M07BW851310 00M07BW851310 USER GUIDE MANUAL , INSTRUCTION SR4500/N CQX1A917Z
/U1B nsp 00M07BW851250 USER GUIDE MANUAL , INSTRUCTION SR4500/U CQX1A915Z
/U1S nsp 00M07BW851250 USER GUIDE MANUAL , INSTRUCTION SR4500/U CQX1A915Z
00MZK08BW0010 00MZK08BW0010 UNIT KIT REMOTE CONTROL UNIT(RC5500SR) HARTSR5500
37 /A1B nsp 90M-ZC000250R MAINS CORD DETACHABLE AUSTRALIA(2PIN) CJA2H001Z
37 /A1S nsp 90M-ZC000250R MAINS CORD DETACHABLE AUSTRALIA(2PIN) CJA2H001Z
37 /N1B 90M-ZC000320R 90M-ZC000320R MAINS CORD 2WIRE 10A/250V (DETACHABLE/EUR) CJA2B054Z
37 /N1G 90M-ZC000320R 90M-ZC000320R MAINS CORD 2WIRE 10A/250V (DETACHABLE/EUR) CJA2B054Z
37 /N1S 90M-ZC000320R 90M-ZC000320R MAINS CORD 2WIRE 10A/250V (DETACHABLE/EUR) CJA2B054Z
NOT STANDARD SPARE PART
/N1B nsp 00M07BW805010 MASS CARTON BOX , MASTER CPG1A766Z
/N1G nsp 00M07BW805010 MASS CARTON BOX , MASTER CPG1A766Z
/N1S nsp 00M07BW805010 MASS CARTON BOX , MASTER CPG1A766Z
/A1B nsp 00M07BW801010 CARTON BOX BOX , OUT CARTON CPG1A765Z
/A1S nsp 00M07BW801010 CARTON BOX BOX , OUT CARTON CPG1A765Z
/F1N nsp 00M07BW801030 CARTON BOX BOX , OUT CARTON CPG1A765X
/K1G nsp 00M07BW801020 CARTON BOX BOX , OUT CARTON CPG1A765Y
/L1G nsp 00M07BW801020 CARTON BOX BOX , OUT CARTON CPG1A765Y
/N1B nsp 00M07BW801010 CARTON BOX BOX , OUT CARTON CPG1A765Z
/N1G nsp 00M07BW801010 CARTON BOX BOX , OUT CARTON CPG1A765Z
/N1S nsp 00M07BW801010 CARTON BOX BOX , OUT CARTON CPG1A765Z
/U1B nsp 00M07BW801010 CARTON BOX BOX , OUT CARTON CPG1A765Z
/U1S nsp 00M07BW801010 CARTON BOX BOX , OUT CARTON CPG1A765Z
