75
NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MJI)
PART NAME DESCRIPTION
POS.NO.
INPUT D411 nsp 00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D412 nsp 00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D413 nsp 00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D414 nsp 00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D415 nsp 00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D416 nsp 00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D417 nsp 00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D418 nsp 00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D419 nsp 00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D420 nsp 00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D421 nsp 00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D422 nsp 00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D423 nsp 00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D424 nsp 00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D425 nsp 00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D426 nsp 00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D427 nsp 00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D428 nsp 00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D451 nsp 00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT D452 nsp 00MHD20015210 DIODE 1SS133T-77 HVD1SS133MT
INPUT IC11 90M-HC108920R 90M-HC108920R IC CS42428-CQ HVICS42428CQ
INPUT IC12 00MHC700400Z0 00MHC700400Z0 IC TC74HCU04AFN HVITC74HCU04AFN
INPUT IC13 00MHC10418030 00MHC10418030 IC LC89057W-VF4-E HVILC89057WVF4E
INPUT IC15 90M-HC108910R 90M-HC108910R IC 74VHC08 HVI74VHC08TTR
INPUT IC16 90M-HC108930R 90M-HC108930R IC 74LCX32 HVI74LCX32TTR
INPUT IC17 90M-HC108910R 90M-HC108910R IC 74VHC08 HVI74VHC08TTR
INPUT IC18 90M-HC108430R 90M-HC108430R IC TC74HC7007AFEL HVITC74HCT7007F
INPUT IC19 00MHC10014880 00MHC10014880 IC CS49400-CQ HVICS49400-CQ
INPUT IC20 90M-HS27AWX0R 90M-HS27AWX0R IC MX29LV400TTC-70 HVIMX29LV400TTC
INPUT IC21 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
INPUT IC22 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
INPUT IC23 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
INPUT IC24 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
INPUT IC26 90M-HC300670R 90M-HC300670R IC REGULATOR +8V HVIL7808CP
INPUT IC27 00MHC3990809F 00MHC3990809F IC REGULATOR HVINJM7908FA
INPUT IC31 90M-HC108900R 90M-HC108900R IC NJW1157 HVINJW1157FC2
INPUT IC32 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
INPUT IC33 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
INPUT IC34 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
INPUT IC35 00MHC10102090 00MHC10102090 IC NJM2068MD-TE1 HVINJM2068MDTE1
INPUT IC41 90M-HS07BWH0R 90M-HS07BWH0R IC HD64F2398F20 HVIHD64F2398F20
INPUT IC42 00MHC10099540 00MHC10099540 IC S-80145ALMC HVIS-80145ALMC
INPUT IC43 90M-HC108390R 90M-HC108390R IC AT24C08N10SC2.7 HVIAT24C08N10SC
INPUT IC45 90M-HC900070R 90M-HC900070R IC +3.3V HVINJM2391DL133
INPUT IC46 90M-HC900060R 90M-HC900060R IC +2.5V HVINJM2391DL125
INPUT J101 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
INPUT J102 nsp nsp CONNECTIVE CORD SN95/PB5 , 0.6 C3A206
INPUT JK31 90M-YT004010R 90M-YT004010R TERMINAL 6P AUDIO CJJ4R019W
INPUT JK32 90M-YT003970R 90M-YT003970R TERMINAL CJJ4P014W
INPUT JK33 90M-YT003970R 90M-YT003970R TERMINAL CJJ4P014W
INPUT JK34 90M-YT004010R 90M-YT004010R TERMINAL 6P AUDIO CJJ4R019W
INPUT JK35 90M-YT003960R 90M-YT003960R TERMINAL CJJ4R037W
INPUT JK36 90M-YT003970R 90M-YT003970R TERMINAL CJJ4P014W
INPUT L101 90M-FC900340R 90M-FC900340R FERRITE CORE HU-1H4516-600JT HLZ9Z014Z
INPUT L111 90M-FN000090R 90M-FN000090R EMI FILTER KLZ9H001Z
INPUT L112 90M-FN000090R 90M-FN000090R EMI FILTER KLZ9H001Z
INPUT L113 90M-FN000090R 90M-FN000090R EMI FILTER KLZ9H001Z
INPUT Q301 00MHT805501B0 00MHT805501B0 TRANSISTOR KTC2874B HVTKTC2874BT
INPUT Q302 00MHT805501B0 00MHT805501B0 TRANSISTOR KTC2874B HVTKTC2874BT
INPUT Q303 00MHT805501B0 00MHT805501B0 TRANSISTOR KTC2874B HVTKTC2874BT
INPUT Q304 00MHT805501B0 00MHT805501B0 TRANSISTOR KTC2874B HVTKTC2874BT
INPUT Q305 00MHT805501B0 00MHT805501B0 TRANSISTOR KTC2874B HVTKTC2874BT
INPUT Q306 00MHT805501B0 00MHT805501B0 TRANSISTOR KTC2874B HVTKTC2874BT
