83
NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MJI)
PART NAME DESCRIPTION
POS.NO.
INPUT R499 /N1G nsp 00MNN05223610 RESISTOR 22 KOHM CRJ10DJ223T
INPUT R499 /N1S nsp 00MNN05223610 RESISTOR 22 KOHM CRJ10DJ223T
INPUT R501 nsp 00MNN05047610 RESISTOR 4.7 OHM CRJ10DJ4R7T
INPUT R502 nsp 00MNN05047610 RESISTOR 4.7 OHM CRJ10DJ4R7T
INPUT R503 nsp 00MNN05047610 RESISTOR 4.7 OHM CRJ10DJ4R7T
INPUT R504 nsp 00MNN05047610 RESISTOR 4.7 OHM CRJ10DJ4R7T
INPUT R505 nsp 00MNN05047610 RESISTOR 4.7 OHM CRJ10DJ4R7T
INPUT R506 nsp 00MNN05047610 RESISTOR 4.7 OHM CRJ10DJ4R7T
INPUT R507 nsp 00MNN05047610 RESISTOR 4.7 OHM CRJ10DJ4R7T
INPUT R508 nsp 00MNN05047610 RESISTOR 4.7 OHM CRJ10DJ4R7T
INPUT R509 nsp 00MNN05101610 RESISTOR 100 OHM CRJ10DJ101T
INPUT R510 nsp 00MNN05101610 RESISTOR 100 OHM CRJ10DJ101T
INPUT R511 nsp 00MNN05101610 RESISTOR 100 OHM CRJ10DJ101T
INPUT R512 nsp 00MNN05101610 RESISTOR 100 OHM CRJ10DJ101T
INPUT R513 nsp 00MNN05832610 RESISTOR 82 KOHM CRJ10DJ823T
INPUT R514 nsp 00MNN05832610 RESISTOR 82 KOHM CRJ10DJ823T
INPUT R515 nsp 00MNN05832610 RESISTOR 82 KOHM CRJ10DJ823T
INPUT R516 nsp 00MNN05832610 RESISTOR 82 KOHM CRJ10DJ823T
INPUT R517 nsp 00MNN05047610 RESISTOR 4.7 OHM CRJ10DJ4R7T
INPUT R531 nsp 00MNN05223610 RESISTOR 22 KOHM CRJ10DJ223T
INPUT R532 nsp 00MNN05223610 RESISTOR 22 KOHM CRJ10DJ223T
INPUT R533 nsp 00MNN05223610 RESISTOR 22 KOHM CRJ10DJ223T
INPUT R534 nsp 00MNN05223610 RESISTOR 22 KOHM CRJ10DJ223T
INPUT R535 nsp 00MNN05223610 RESISTOR 22 KOHM CRJ10DJ223T
INPUT R536 nsp 00MNN05223610 RESISTOR 22 KOHM CRJ10DJ223T
INPUT R537 nsp 00MNN05223610 RESISTOR 22 KOHM CRJ10DJ223T
INPUT R538 nsp 00MNN05223610 RESISTOR 22 KOHM CRJ10DJ223T
INPUT R539 nsp 00MNN05332610 RESISTOR 3.3 KOHM CRJ10DJ332T
INPUT R903 nsp 00MNN05101610 RESISTOR 100 OHM CRJ10DJ101T
INPUT R907 nsp 00MNN05101610 RESISTOR 100 OHM CRJ10DJ101T
INPUT X101 90M-JX001180R 90M-JX001180R CRYSTAL 12288HZ HOX12288E320TF
INPUT XC11 90M-JX001190R 90M-JX001190R CRYSTAL 20MHZ HOX20000E220TF
MAIN PCB (CUP11695-1)
MAIN BN20 nsp nsp CONNECTIVE CORD CWB3FB03280UP
MAIN BN81 nsp nsp CONNECTIVE CORD CWB1C902050EN
MAIN BN87 nsp nsp CONNECTIVE CORD CWB2B905550EN
MAIN BN90 /A1B nsp nsp CONNECTIVE CORD CWB4F232550PU
MAIN BN90 /A1S nsp nsp CONNECTIVE CORD CWB4F232550PU
MAIN BN90 /F1N nsp nsp CONNECTIVE CORD CWB4F232550PU
MAIN BN90 /K1G nsp nsp CONNECTIVE CORD CWB4F232550PU
MAIN BN90 /N1B nsp nsp CONNECTIVE CORD CWB4F232550PU
MAIN BN90 /N1G nsp nsp CONNECTIVE CORD CWB4F232550PU
MAIN BN90 /N1S nsp nsp CONNECTIVE CORD CWB4F232550PU
MAIN BN93 nsp nsp CONNECTIVE CORD CWB1C902250BM
MAIN BN98 90M-YJ002810R 90M-YJ002810R JACK 8P BJP08GA130ZK
MAIN C115 nsp nsp CERAMIC CAP. 220PF 50V KB CCKT1H221KB
MAIN C116 nsp nsp CERAMIC CAP. 220PF 50V KB CCKT1H221KB
MAIN C117 nsp nsp CERAMIC CAP. 220PF 50V KB CCKT1H221KB
MAIN C118 nsp nsp CERAMIC CAP. 220PF 50V KB CCKT1H221KB
MAIN C119 nsp nsp CERAMIC CAP. 220PF 50V KB CCKT1H221KB
MAIN C120 nsp nsp CERAMIC CAP. 220PF 50V KB CCKT1H221KB
MAIN C121 nsp nsp CERAMIC CAP. 220PF 50V KB CCKT1H221KB
MAIN C122 nsp nsp CERAMIC CAP. 220PF 50V KB CCKT1H221KB
MAIN C501 nsp 00MOA10603540 ELECT CAP. 10UF 35V CCEA1VH100T
MAIN C502 nsp 00MOA10603540 ELECT CAP. 10UF 35V CCEA1VH100T
MAIN C503 nsp 00MOA10603540 ELECT CAP. 10UF 35V CCEA1VH100T
MAIN C504 nsp 00MOA10603540 ELECT CAP. 10UF 35V CCEA1VH100T
MAIN C505 nsp 00MOA10603540 ELECT CAP. 10UF 35V CCEA1VH100T
MAIN C506 nsp nsp CERAMIC CAP. 330PF 50V KB CCKT1H331KB
MAIN C507 nsp nsp CERAMIC CAP. 330PF 50V KB CCKT1H331KB
MAIN C508 nsp nsp CERAMIC CAP. 330PF 50V KB CCKT1H331KB
MAIN C509 nsp nsp CERAMIC CAP. 330PF 50V KB CCKT1H331KB
MAIN C510 nsp nsp CERAMIC CAP. 330PF 50V KB CCKT1H331KB
