NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MJI)
PART NAME DESCRIPTION
POS.NO.
MAIN R976 nsp nsp RESISTOR 330 OHM 1/5W J CRD20TJ331T
MAIN R977 nsp nsp RESISTOR 330 OHM 1/5W J CRD20TJ331T
MAIN R978 nsp nsp RESISTOR 330 OHM 1/5W J CRD20TJ331T
MAIN R979 nsp nsp RESISTOR 39K OHM 1/5W CRD20TJ393T
MAIN R980 nsp nsp RESISTOR 15K OHM 1/5W J CRD20TJ153T
MAIN R981 nsp nsp RESISTOR 56 OHM 1/4W J CRD25TJ560T
MAIN R990 nsp nsp RESISTOR 10 OHM 1W CRG1ANJ100H
MAIN R993 nsp nsp RESISTOR 10 OHM 1W CRG1ANJ100H
MAIN R994 nsp nsp RESISTOR 10 OHM 1W CRG1ANJ100H
MAIN R995 nsp nsp RESISTOR 10 OHM 1W CRG1ANJ100H
MAIN R996 nsp nsp RESISTOR 10 OHM 1W CRG1ANJ100H
MAIN R997 nsp nsp RESISTOR 10 OHM 1W CRG1ANJ100H
MAIN R999 nsp nsp RESISTOR 10 OHM 1W CRG1ANJ100H
MAIN RY94 90M-LY000340R 90M-LY000340R RELAY SDT-S-112DMR HSL1A008ZE
MAIN RY95 00MLY20240490 00MLY20240490 RELAY 5GPA-28 DC24 HSL3B013ZE
MAIN RY96 00MLY20240490 00MLY20240490 RELAY 5GPA-28 DC24 HSL3B013ZE
MAIN T902 /A1B nsp 90M-TS002210R MAINS TRANSF. SR4500/N1 CLT5I004ZE
MAIN T902 /A1S nsp 90M-TS002210R MAINS TRANSF. SR4500/N1 CLT5I004ZE
MAIN T902 /F1N nsp 90M-TS002230R MAINS TRANSF. SR4500/F1 CLT5I004ZJ
MAIN T902 /K1G nsp 90M-TS002220R MAINS TRANSF. SR4500/K1 CLT5I004ZH
MAIN T902 /L1G nsp 90M-TS002240R MAINS TRANSF. SR4500/L1 CLT5I004ZS
MAIN T902 /N1B 90M-TS002210R 90M-TS002210R MAINS TRANSF. SR4500/N1 CLT5I004ZE
MAIN T902 /N1G 90M-TS002210R 90M-TS002210R MAINS TRANSF. SR4500/N1 CLT5I004ZE
MAIN T902 /N1S 90M-TS002210R 90M-TS002210R MAINS TRANSF. SR4500/N1 CLT5I004ZE
MAIN T902 /U1B nsp 90M-TS002190R MAINS TRANSF. SR4500/U1 CLT5I004ZU
MAIN T902 /U1S nsp 90M-TS002190R MAINS TRANSF. SR4500/U1 CLT5I004ZU
MAIN TH91 90M-HP000060R 90M-HP000060R TERMINAL P42T7D330BW20 KRTP42T7D330B
TUNER IN PCB (CUP11695-2)
TUNER IN C231 /F1N nsp nsp CERAMIC CAP. 470PF 50V KB HCBS1H471KBT
TUNER IN C232 /F1N nsp nsp CERAMIC CAP. 470PF 50V KB HCBS1H471KBT
TUNER IN C233 /F1N nsp 00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
TUNER IN C234 /F1N nsp 00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
TUNER IN CN25 /F1N nsp nsp JACK 4P KJP04GA19ZM
TUNER IN JK96 /F1N nsp 90M-YT003180R TERMINAL CJJ4N063Z
TUNER IN R231 /F1N nsp nsp RESISTOR 100 OHM 1/5W J CRD20TJ101T
TUNER IN R232 /F1N nsp nsp RESISTOR 100 OHM 1/5W J CRD20TJ101T
TUNER IN R233 /F1N nsp nsp RESISTOR 82K OHM 1/5W J CRD20TJ823T
TUNER IN R234 /F1N nsp nsp RESISTOR 82K OHM 1/5W J CRD20TJ823T
BIAS T.R PCB
BIAS TR C851 nsp 00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
BIAS TR CN81 nsp nsp JACK 2P ANGLE CJP02GB46ZY
BIAS TR Q851 90M-HT800120R 90M-HT800120R TRANSISTOR KTC3114A HVTKTC3114A
BIAS TR R874 nsp nsp RESISTOR 330 OHM 1/5W J CRD20TJ331T
BIAS TR R882 nsp nsp RESISTOR 1.2K OHM 1/5W J CRD20TJ122T
BIAS TR VR81 90M-RA001100R 90M-RA001100R TRIMMING RESIST 220 OHM HVN1RA221B01T
REGULATOR PCB (CUP11696Z)
REGULATOR C922 nsp 00MOA10702520 ELECT CAP. 100UF 25V CCEA1EH101T
REGULATOR C923 nsp 00MOA10702520 ELECT CAP. 100UF 25V CCEA1EH101T
REGULATOR C924 nsp 00MOA10702520 ELECT CAP. 100UF 25V CCEA1EH101T
REGULATOR C925 nsp nsp CERAMIC CAP. 0.022UF 50V ZF CCKT1H223ZF
REGULATOR C926 nsp nsp CERAMIC CAP. 0.022UF 50V ZF CCKT1H223ZF
REGULATOR C927 nsp nsp CERAMIC CAP. 0.022UF 50V ZF CCKT1H223ZF
REGULATOR C928 nsp 00MOA68801620 ELECT CAP. 6800UF 16V CCEA1CH682E
REGULATOR C929 nsp 00MOA22802520 ELECT CAP. 2200UF 25V CCEA1EH222E
REGULATOR C930 nsp 00MOA22802520 ELECT CAP. 2200UF 25V CCEA1EH222E
REGULATOR CN96 nsp nsp JACK 8P STRAIGHT CJP08GA01ZY
REGULATOR CN98 90M-YP100240R 90M-YP100240R JACK 8P BJP08GB131ZK
REGULATOR D904 nsp 90M-HD201730R DIODE 1N4003 KVD1N4003ST
REGULATOR D905 nsp 90M-HD201730R DIODE 1N4003 KVD1N4003ST
REGULATOR D906 nsp 90M-HD201730R DIODE 1N4003 KVD1N4003ST
REGULATOR D907 nsp 90M-HD201730R DIODE 1N4003 KVD1N4003ST
REGULATOR IC91 90M-HC300650R 90M-HC300650R IC REGULATOR +12V HVIL7812CP
REGULATOR IC92 90M-HC300660R 90M-HC300660R IC REGULATOR -12V HVIL7912CP
