Marantz SR5009/U1B - Video Pcb; Preout Pcb

4. VIDEO PCB
Proceeding : TOP COVER → BACK CHASSIS → HDMI PCB → VIDEO PCB
(1) Remove the connector wire.
5. PREOUT PCB
Proceeding : TOP COVER → BACK CHASSIS → HDMI PCB → VIDEO PCB → PREOUT PCB
(1) Remove the connector wire.
Front side
CN5000CN5001CN5004
CN5003
Front side
CN5601
CN5602
TO CP401
