MAIN
1
MAIN PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed b
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
BK : Black model SG : Silver gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D4000-4004 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 5
D4007 00D2760401905 D,SWITCHING 1SS133-DO34-AXIAL LRC K000013300040S 1
D4008 963203500300D D,RECTIFIER BRIDGE DIODE BRIDGE D10SB60 600V/10A STRAIGHT TYPE K047100600220S 1
D4009,4010 963201500160D D,SWITCHING 1N4007 52REEL 1000V 1A K000400700220S 2
D4013 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1
D4014 963201500160D D,SWITCHING 1N4007 52REEL 1000V 1A K000400700220S 1
D4016 00D2760401905 D,SWITCHING 1SS133-DO34-AXIAL LRC K000013300040S 1
D4017 963201500160D D,SWITCHING 1N4007 52REEL 1000V 1A K000400700220S 1
D4019 00D2760401905 D,SWITCHING 1SS133-DO34-AXIAL LRC K000013300040S 1
D4020 963201500160D D,SWITCHING 1N4007 52REEL 1000V 1A K000400700220S 1
D4022 963201500160D D,SWITCHING 1N4007 52REEL 1000V 1A K000400700220S 1
D4023 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1
D4025 963201500160D D,SWITCHING 1N4007 52REEL 1000V 1A K000400700220S 1
D4026 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1
D4027-4030 963201500160D D,SWITCHING 1N4007 52REEL 1000V 1A K000400700220S 4
D4031,4032 00D2760401905 D,SWITCHING 1SS133-DO34-AXIAL LRC K000013300040S 2
D4033-4036 963201500160D D,SWITCHING 1N4007 52REEL 1000V 1A K000400700220S 4
D4037 00D2760401905 D,SWITCHING 1SS133-DO34-AXIAL LRC K000013300040S 1
D4038 963201500160D D,SWITCHING 1N4007 52REEL 1000V 1A K000400700220S 1
D4039-4044 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 6
D4703 963201500170D D,SWITCHING CHIP LBAS16HT1G FAST SWITCHING SOD-323 K005041480230S 1
IC4000 00D2631100005 IC,LINEAR-REGULATOR KIA7805API,20W-TO220IS MOLD J126780500110S 1
IC4001 00D2631099006 IC,LINEAR-REGULATOR KIA7905PI,20W-TO220IS MOLD J126790500070S 1
IC4002 00D2631104001 IC,LINEAR-REGULATOR BA08T 8V TO220FP LOW-DROP POSITIVE VOLTAGE REG J126080000020S 1
IC4003 00D2631100005 IC,LINEAR-REGULATOR KIA7805API,20W-TO220IS MOLD
J126780500110S 1
IC4004 00D2631251006 IC,LINEAR-REGULATOR KIA7908PI,20W-TO220IS J126790800060S 1
IC4005 963232100400S IC,LINEAR OP UTC4580E SOP8 DUAL OP AMP J121458001010S 1
IC4700 00D2631286903 IC,LINEAR-REGULATOR PQ120DNA1ZPH 12V 1A SC-63 J126120010010S 1
IC4701 236810090504S IC,LOGIC-INTERFACE ILX3232D 3V3 RS232 INTERFACE TRANSCEIVER SOP16 J046323200020S 1
Q4005-4010 963214500310S SEMI,CHIP TR/NPN 2SC RT1N237C 02W/SC-59 ISAHAYA J522102371210S 6
ZD4002 963202500330D D,ZENER ZJ68B-05W/5MA-52MM SEMTECH K06006R844522S 1
ZD4157,4158 963202500290D D,ZENER ZJ36B-05W/5MA-52MM SEMTECH K06003R644522S 2
ZD4700 963202500400S D,ZENER ZJ16B-05W/5MA-52MM SEMTECH K06016R044522S 1
RESISTOR GROUP
R4000,4001 963125010110S R,METAL FILM 100PPM 470-J,2W-RREEL C060047166060S 2
R4002 nsp R,CARBON FILM 10-J,1/5W-52RE-AX C00001006P520S 1
R4003 963125010100S R,METAL FILM 100PPM 10-J 2W, R-REEL C060010066050S 1
R4004 nsp R,CARBON FILM 10-J,1/5W-52RE-AX C00001006P520S 1
R4005 963125010100S R,METAL FILM 100PPM 10-J 2W, R-REEL C060010066050S 1
R4006 nsp R,CARBON FILM 10-J,1/5W-52RE-AX C00001006P520S 1
R4007 963125010100S R,METAL FILM 100PPM 10-J 2W, R-REEL C060010066050S 1
R4008 nsp R,CARBON FILM 10-J,1/5W-52RE-AX C00001006P520S 1
R4009 963125010100S R,METAL FILM 100PPM 10-J 2W, R-REEL C060010066050S 1
R4010 nsp R,CARBON FILM 10-J,1/5W-52RE-AX C00001006P520S 1
R4011 963125010100S R,METAL FILM 100PPM 10-J 2W, R-REEL C060010066050S 1
R4012 nsp R,CARBON FILM 10-J,1/5W-52RE-AX C00001006P520S 1
R4013 963125010100S R,METAL FILM 100PPM 10-J 2W, R-REEL C060010066050S 1
R4014 nsp R,CARBON FILM 10-J,1/5W-52RE-AX C00001006P520S 1
R4015 963125010100S R,METAL FILM 100PPM 10-J 2W, R-REEL C060010066050S 1
R4016 nsp R,CARBON FILM 100-J,1/5W-52RE-AX C00001016P520S 1
R4017-4020 nsp R,CARBON FILM 20-J,1/5W-52RE-AX C00002006P520S 4
R4025-4027 963125500070D R,METAL FILM 100PPM 11K-J,1W-RREEL C060011265050S 3
R4029
nsp R,METAL FILM 100PPM 10K-J,1/4W-RREEL C060103063050S 1
R4035 nsp R,CHIP THICK 0-J,1/10W-2012REEL C200000060200S 1
R4036-4038 nsp R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160S 3
R4039,4040 nsp R,CHIP THICK 82K-J,1/16W-1608REEL C20008236M160S 2
R4041 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R4042 nsp R,CHIP THICK 33-J,1/16W-1608REEL C20003306M160S 1
R4043 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R4044,4045 nsp R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160S 2
R4046 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S 1
R4047 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R4048 nsp R,CHIP THICK 33-J,1/16W-1608REEL C20003306M160S 1
R4049 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R4052 nsp R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160S 1
R4056 nsp R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160S 1
R4057 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R4058 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R4059 nsp R,CHIP THICK 22K-J,1/16W-1608REEL C20002236M160S 1
R4060 nsp R,CHIP THICK 330K-J,1/16W-1608REEL C20003346M160S 1
R4061 nsp R,CHIP THICK 22K-J,1/16W-1608REEL C20002236M160S 1
R4062 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R4063 nsp R,CHIP THICK 33K-J,1/16W-1608REEL C20003326M160S 1
R4064 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S 1
R4065 nsp R,CHIP THICK 33K-J,1/16W-1608REEL C20003336M160S 1
R4066,4067 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 2
R4069 963129501010S R,CEMENT MPR 001-J/5W W14*H18 9MM PITCH C144R01069000S 1
R4070 nsp R,CARBON FILM 20-J,1/5W-52RE-AX C00002006P520S 1
R4708,4709 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S 2
R4710 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R4711 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S 1
R4714 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S 1
CAPACIITORS GROUP
C4000 nsp C,FILM POLYESTER MI-0047UF-J/50V-5RE D020473167050S 1
C4001 nsp C,CERAMIC CHIP HIK X7R)2200PF-K/50V-1608REEL D011222777160S 1
C4003 nsp C,FILM POLYESTER MI-0047UF-J/50V-5RE D020473167050S 1
C4004 nsp C,CERAMIC CHIP HIK X7R)2200PF-K/50V-1608REEL D011222777160S 1
C4006,4007 nsp C,FILM POLYESTER MI-0047UF-J/50V-5RE D020473167050S 2
C4008 nsp C,CERAMIC CHIP HIK X7R)2200PF-K/50V-1608REEL D011222777160S 1
C4010,4011 nsp C,FILM POLYESTER MI-0047UF-J/50V-5RE D020473167050S 2
C4012 nsp C,CERAMIC CHIP HIK X7R)2200PF-K/50V-1608REEL D011222777160S 1
C4014 nsp C,CERAMIC CHIP HIK X7R)2200PF-K/50V-1608REEL D011222777160S 1
C4016,4017 nsp C,FILM POLYESTER MI-0047UF-J/50V-5RE D020473167050S 2
C4018 nsp C,CERAMIC CHIP HIK X7R)2200PF-K/50V-1608REEL D011222777160S 1
