Marantz SR5009/U1B - Page 170

INPUT
7
INPUT PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed b
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
BK : Black model SG : Silver gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
IC4200 963239000650S IC,ELECT VR R2A15218FP-U00R 8CH-VOL WITH 11 INPUT QFP100P J084152180010S 1
IC5201 963232100400S IC,LINEAR OP UTC4580E SOP8 DUAL OP AMP J121458001010S 1
IC5202 00D2631193902 IC,ELECT VR BD3812F-E2 2CH-VOL SOP14P J084381200010S 1
U1047 963232100390S IC,LINEAR OP NJM8080G SOP8 DUAL OP AMP J121808000010S 1
U1049 963232100390S IC,LINEAR OP NJM8080G SOP8 DUAL OP AMP J121808000010S 1
U1051 963232100390S IC,LINEAR OP NJM8080G SOP8 DUAL OP AMP J121808000010S 1
U1053 963232100390S IC,LINEAR OP NJM8080G SOP8 DUAL OP AMP J121808000010S 1
RESISTOR GROUP
R1999 nsp R,CHIP THICK 15K-J,1/16W-1608REEL C20001536M160S 1
R2000 nsp R,CHIP THICK 820-J,1/16W-1608REEL C20008216M160S 1
R2001 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R2002 nsp R,CHIP THICK 15K-J,1/16W-1608REEL C20001536M160S 1
R2003 nsp R,CHIP THICK 820-J,1/16W-1608REEL C20008216M160S 1
R2005,2006 nsp R,CHIP THICK 11K-J,1/16W-1608REEL C20001136M160S 2
R2009 nsp R,CHIP THICK 11K-J,1/16W-1608REEL C20001136M160S 1
R2010 nsp R,CHIP THICK 15K-J,1/16W-1608REEL C20001536M160S 1
R2011 nsp R,CHIP THICK 820-J,1/16W-1608REEL C20008216M160S 1
R2012 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R2013 nsp R,CHIP THICK 15K-J,1/16W-1608REEL C20001536M160S 1
R2014 nsp R,CHIP THICK 820-J,1/16W-1608REEL C20008216M160S 1
R2015 nsp R,CHIP THICK 11K-J,1/16W-1608REEL C20001136M160S 1
R2017 nsp R,CHIP THICK 15K-J,1/16W-1608REEL C20001536M160S 1
R2018 nsp R,CHIP THICK 820-J,1/16W-1608REEL C20008216M160S 1
R2019 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R2021 nsp R,CHIP THICK 15K-J,1/16W-1608REEL C20001536M160S 1
R2022 nsp
R,CHIP THICK 820-J,1/16W-1608REEL C20008216M160S 1
R2024,2025 nsp R,CHIP THICK 11K-J,1/16W-1608REEL C20001136M160S 2
R2030 nsp R,CHIP THICK 300K-J,1/16W-1608REEL C20003046M160S 1
R2031 nsp R,CHIP THICK 24K-J,1/16W-1608REEL C20002436M160S 1
R2034 nsp R,CHIP THICK 15K-J,1/16W-1608REEL C20001536M160S 1
R2035 nsp R,CHIP THICK 820-J,1/16W-1608REEL C20008216M160S 1
R2036 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R2038 nsp R,CHIP THICK 15K-J,1/16W-1608REEL C20001536M160S 1
R2039 nsp R,CHIP THICK 820-J,1/16W-1608REEL C20008216M160S 1
R2040 nsp R,CHIP THICK 24K-J,1/16W-1608REEL C20002436M160S 1
R2041 nsp R,CHIP THICK 300K-J,1/16W-1608REEL C20003046M160S 1
R2044 nsp R,CHIP THICK 15K-J,1/16W-1608REEL C20001536M160S 1
R2045 nsp R,CHIP THICK 820-J,1/16W-1608REEL C20008216M160S 1
R2046 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R2047 nsp R,CHIP THICK 15K-J,1/16W-1608REEL C20001536M160S 1
R2048 nsp R,CHIP THICK 820-J,1/16W-1608REEL C20008216M160S 1
R2051,2052 nsp R,CHIP THICK 16K-J,1/16W-1608REEL C20001636M160S 2
R2056 nsp R,CHIP THICK 16K-J,1/16W-1608REEL C20001636M160S 1
R2058 nsp R,CHIP THICK 15K-J,1/16W-1608REEL C20001536M160S 1
R2059 nsp R,CHIP THICK 820-J,1/16W-1608REEL C20008216M160S 1
R2060 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R2062 nsp R,CHIP THICK 15K-J,1/16W-1608REEL C20001536M160S 1
R2063 nsp R,CHIP THICK 820-J,1/16W-1608REEL C20008216M160S 1
R2064 nsp R,CHIP THICK 16K-J,1/16W-1608REEL C20001636M160S 1
R2069 nsp R,CHIP THICK 15K-J,1/16W-1608REEL C20001536M160S 1
R2070 nsp R,CHIP THICK 820-J,1/16W-1608REEL C20008216M160S 1
R2071 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R2072
nsp R,CHIP THICK 15K-J,1/16W-1608REEL C20001536M160S 1
R2073 nsp R,CHIP THICK 820-J,1/16W-1608REEL C20008216M160S 1
R2076,2077 nsp R,CHIP THICK 11K-J,1/16W-1608REEL C20001136M160S 2
R2081 nsp R,CHIP THICK 11K-J,1/16W-1608REEL C20001136M160S 1
R2082 nsp R,CHIP THICK 15K-J,1/16W-1608REEL C20001536M160S 1
R2083 nsp R,CHIP THICK 820-J,1/16W-1608REEL C20008216M160S 1
R2084 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R2085 nsp R,CHIP THICK 15K-J,1/16W-1608REEL C20001536M160S 1
R2086 nsp R,CHIP THICK 820-J,1/16W-1608REEL C20008216M160S 1
R2087 nsp R,CHIP THICK 11K-J,1/16W-1608REEL C20001136M160S 1
R4205-4211 nsp R,CHIP THICK 470-J,1/16W-1608REEL C20004716M160S 7
R4216-4221 nsp R,CHIP THICK 820K-J,1/16W-1608REEL C20008246M160S 6
R4244,4245 nsp R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160S 2
R4248 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R4249-4254 nsp R,CHIP THICK 470K-J,1/16W-1608REEL C20004746M160S 6
R4257 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R4259-4262 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 4
R4263-4270 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 8
R4288-4290 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 3
R4292-4294 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 3
R4326 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R4370-4376 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 7
R4550 nsp R,CHIP THICK 470-J,1/16W-1608REEL C20004716M160S 1
R4551,4552 nsp R,CHIP THICK 820K-J,1/16W-1608REEL C20008246M160S 2
R5300 nsp R,CHIP THICK 47-J,1/16W-1608REEL C20004706M160S 1
R5304 nsp R,CHIP THICK 47K-J,1/16W-1608REEL C20004736M160S 1
R5310 nsp R,CHIP THICK 47K-J,1/16W-1608REEL C20004736M160S 1
R5311 nsp R,CHIP THICK 47-J,1/16W-1608REEL C20004706M160S 1
R5312 nsp R,CHIP THICK 4.7K-J,1/16W-1608REEL C20004726M160S 1
R5313,5314 nsp R,CHIP THICK 33-J,1/16W-1608REEL C20003306M160S 2
R5323 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 1
R5326 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 1
R5331 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 1
R5336 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 1
R5337,5338 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S 2
R5340,5341 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 2
R5342 nsp R,CHIP THICK 11K-J,1/16W-1608REEL C20001136M160S 1
R5343 nsp R,CHIP THICK 2.2K-J,1/16W-1608REEL C20002226M160S 1
R5344 nsp R,CHIP THICK 11K-J,1/16W-1608REEL C20001136M160S 1
R5345 nsp R,CHIP THICK 2.2K-J,1/16W-1608REEL C20002226M160S 1
CAPACIITORS GROUP
C2137 00D2570505910 C,CERAMIC CHIP T.C CH)1500PF-J/50V-1608REEL GRM1882C1H152JA01D D010152167165S 1
