Input
CVBS / COMPONENT
A
Check the input signal to the
VIDEO DECODER.
Can a signal be conrmed at
the following points?
HDMI PCB
V : R2092
COMPONENT-Y : R2089
COMPONENT-Cb : R2091
COMPONENT-Cr : R2090
Check the connection between
the PCBs.
Input CVBS：Check B
Input COPONENT：Check C
Input CVBS NG：Check B-4
Output COMPONENT NG : Check C-4
Output HDMI NG : See 3. HDMI/DVI
NO NO
YES
q
