Marantz SR6006/U1B - Page 29

Conrmation item Setting and display
Details of how to operate remote
controller
Output sequence of remote control codes
b
It is useful to form a macro program.
Contents of conrmation Remarks
7
Analog Audio (signal) Path
(ZONE2)
Amp assign : ZONE2
ZONE2 Function : Source
Zone2 Vol -20dB
Display:
D i a g M o d e
A 0 7
D V D
1.Press [AMP]
2.Press [Z2]
3.Press [STANDBY]
q
ZONE2 POWER OFF ·Input : Analog / Output : Speakers (SURR BACK L/R)
·Input : Analog / Output : Pre OUT(ZONE2 L/R)
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [Z3]
5.Press [STANDBY]
w
ZONE3 POWER OFF
6.Press [AMP]
7.Press [P2]
e
P2
(Initialization & Amp assign ZONE2 &
SURROUND mode : Multi ch STEREO &
ZONE2 Volume -20dB)
8.Press [Z2]
9.Press [POWER ON]
e
ZONE2 POWER ON
10.Press [AMP]
11.Press [DVD] twice
r
DVD (Main Zone)
8
Amp Assign (signal) Path
(Amp Assign : ZONE3)
Amp assign : ZONE3
SURROUND mode : Multi ch STEREO
Zone3 Vol -20dB
Display:
D i a g M o d e
A 0 8
D V D
1.Press [AMP]
2.Press [Z2]
3.Press [STANDBY]
q
ZONE2 POWER OFF ·Input : Analog / Output : Speakers (SURR BACK L/R)
·Input : Analog / Output : Pre OUT(ZONE3 L/R)
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [Z3]
5.Press [STANDBY]
w
ZONE3 POWER OFF
6.Press [AMP]
7.Press [P3]
e
P3
(Initialization & Amp assign ZONE2 &
SURROUND mode : Multi ch STEREO &
ZONE2 Volume -20dB)
8.Press [Z3]
9.Press [POWER ON]
r
ZONE2 POWER ON
10.Press [AMP]
11.Press [DVD] twice
t
DVD (Main Zone)
9
Amp Assign (signal) Path
(Amp Assign : SPKR-C)
Amp assign : BiAMP
SURROUND mode : Multi ch STEREO
Vol -20dB
Display:
D i a g M o d e
A 1 1
D V D
1.Press [AMP]
2.Press [Z2]
3.Press [STANDBY]
q
ZONE2 POWER OFF ·Input : Analog / Output : Speakers (SURR BACK L/R)
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [Z3]
5.Press [STANDBY]
w
ZONE3 POWER OFF
6.Press [AMP], Select "MAIN"
7.Press [DISPLAY]
e
DISPLAY
(Initialization & Amp assign SPKR-C &
SURROUND mode : Multi ch STEREO &
Volume -20dB)
8.Press [DVD] twice
r
DVD (Main Zone)
10
Amp Assign (signal) Path
(Amp Assign : Front Height)
Amp assign : Front Height
SURROUND mode : Multi ch STEREO
Vol -20dB
Surround Parameter-Speaker : F.Height
Display:
D i a g M o d e
A 1 4
D V D
1.Press [AMP]
2.Press [Z2]
3.Press [STANDBY]
q
ZONE2 POWER OFF ·Input : Analog / Output : Speakers (SURR BACK L/R)
·Input : Analog / Output : Pre OUT(SB L/R)
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [Z3]
5.Press [STANDBY]
w
ZONE3 POWER OFF
6.Press [AMP]
7.Press [+10/SLEEP]
e
+10/SLEEP (Main Zone)
(Initialization & Amp assign Front Height &
SURROUND mode : Multi ch STEREO &
Volume -20dB)
8.Press [DVD] twice
r
DVD (Main Zone)
11
Amp Assign (signal) Path
(Amp Assign : Front Wide)
Amp assign : Front Wide
SURROUND mode : Multi ch STEREO
Vol -20dB
Surround Parameter-Speaker : F.Wide
Display:
D i a g M o d e
A 1 5
D V D
1.Press [AMP]
2.Press [Z2]
3.Press [STANDBY]
q
ZONE2 POWER OFF ·Input : Analog / Output : Speakers (SURR BACK L/R)
·Input : Analog / Output : Pre OUT(SB L/R)
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [Z3]
5.Press [STANDBY]
w
ZONE3 POWER OFF
6.Press [AMP]
7.Press [SEARCH/INFO]
e
SEARCH/INFO
(Initialization & Amp assign NORMAL &
SURROUND mode : Multi ch STEREO &
Volume -20dB)
8.Press [DVD] twice
r
DVD (Main Zone)
12
Front-B (signal) Path Amp assign : Normal
SPKR A/B : SPKR-B
SURROUND mode : Multi ch STEREO
Vol -20dB
Display:
D i a g M o d e
A 1 6
D V D
1.Press [AMP]
2.Press [Z2]
3.Press [STANDBY]
q
ZONE2 POWER OFF ·Input : Analog / Output : Speakers (FRONT B L/R)
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [Z3]
5.Press [STANDBY]
w
ZONE3 POWER OFF
6.Press [AMP]
7.Press [SPEAKER A/B]
e
SPEAKER A/B
(Initialization & SPKR A/B SPKR-B &
SURROUND mode : Multi ch STEREO &
Volume -20dB)
8.Press [DVD] twice
r
DVD (Main Zone)
g.16
g.17
g.18
g.19
g.19
g.15
29
