4.5. Audio system conrmation items
g.XX : Refer to the block diagram of the g.XXth.
Conrmation item Setting and display
Details of how to operate remote
controller
Output sequence of remote control codes
b
It is useful to form a macro program.
Contents of conrmation Remarks
1
Analog (signal) Path Input Mode : Fixed ANALOG
SURROUND mode : DIRECT
Amp assign : NORMAL
Display:
D i a g M o d e
A 0 1
D V D
1.Press [AMP]
2.Press [Z2]
3.Press [STANDBY]
q
ZONE2 POWER OFF ·Input : Analog / Output : Speakers (Front L/R)
·Input : Analog / Output : Pre OUT(Front L/R)
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [Z3]
5.Press [STANDBY]
w
ZONE3 POWER OFF
6.Press [AMP]
7.Press [7/T.TONE]
e
KEY7/T.TONE (Main Zone)
(Initialization & Amp assign NORMAL&
Input Mode Fixed ANALOG &
SURROUND mode DIRECT)
8.Press [DVD] twice
r
DVD (Main Zone)
2
DIGITAL (signal) Path
(MAIN)
Input Mode : Fixed DIGITAL
Amp assign : NORMAL
Display:
D i a g M o d e
A 0 2
D V D
1.Press [AMP]
2.Press [Z2]
3.Press [STANDBY]
q
ZONE2 POWER OFF ·Input : Digital / Output : Speakers (Front L/R)
·Input : Digital / Output : Pre OUT(Front L/R)
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [Z3]
5.Press [STANDBY]
w
ZONE3 POWER OFF
6.Press [AMP]
7.Press [8/CH LVL]
e
KEY8/CH LVL (Main Zone)
(Initialization & Amp assign NORMAL&
Input Mode Fixed ANALOG)
8.Press [DVD] twice
r
DVD (Main Zone)
3
DIGITAL (signal) Path
(ZONE2)
Input Mode : Fixed DIGITAL
Amp assign : ZONE2
ZONE2 Function : Source
Display:
D i a g M o d e
A 0 3
D V D
1.Press [AMP]
2.Press [Z2]
3.Press [STANDBY]
q
ZONE2 POWER OFF ·Input : Digital / Output : Speakers (SURR BACK L/R)
·Input : Digital / Output : LINE OUT(ZONE2 L/R)
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [Z3]
5.Press [STANDBY]
w
ZONE3 POWER OFF
6.Press [AMP]
7.Press [INTERNET RADIO]
e
INTERNET RADIO (Main Zone)
(Initialization & Amp assign ZONE2 &
Input Mode Fixed DIGITAL)
8.Press [Z2]
9.Press [POWER ON]
r
ZONE2 POWER ON
10.Press [AMP]
11.Press [DVD] twice
t
DVD (MAIN ZONE)
4
DIGITAL (signal) Path
(ZONE3)
Input Mode : Fixed DIGITAL
Amp assign : ZONE3
ZONE3 Function : Source
Display:
D i a g M o d e
A 0 4
D V D
1.Press [AMP]
2.Press [Z2]
3.Press [STANDBY]
q
ZONE2 POWER OFF ·Input : Digital / Output : Speakers (SURR BACK L/R)
·Input : Digital / Output : LINE OUT(ZONE3 L/R)
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [Z3]
5.Press [STANDBY]
w
ZONE3 POWER OFF
6.Press [AMP]
7.Press [P1]
e
P1 (Main Zone)
(Initialization & Amp assign ZONE3 &
Input Mode Fixed DIGITAL)
8.Press [Z3]
9.Press [POWER ON]
r
ZONE3 POWER ON
10.Press [AMP]
11.Press [DVD] twice
t
DVD (MAIN ZONE)
5
HDMI (signal) Path Input Mode : Fixed HDMI
Amp assign : NORMAL
Display:
D i a g M o d e
A 0 5
D V D
1.Press [AMP]
2.Press [Z2]
3.Press [STANDBY]
q
ZONE2 POWER OFF ·Input : HDMI / Output : Speakers (Front L/R)
·Input : HDMI / Output : Pre OUT(Front L/R), SW(20Hz)
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [Z3]
5.Press [STANDBY]
w
ZONE3 POWER OFF
5.Press [AMP]
6.Press [SURROUND]
e
SURROUND
(Initialization & Amp assign NORMAL &
Input Mode Fixed HDMI)
7.Press [DVD] twice
r
DVD (Main Zone)
6
A/D (signal) Path
(Main Zone)
Amp assign : NORMAL
SURROUND mode : Multi ch STEREO
Vol -20dB
Speaker Cong : SSSSY
(Front/Center/Surround/SourroundBack :
Small, SW : Yes)
Display:
D i a g M o d e
A 0 6
D V D
1.Press [AMP]
2.Press [Z2]
3.Press [STANDBY]
q
ZONE2 POWER OFF ·Input : Analog / Output : Speakers (Front L/R)
·Input : Analog / Output : Pre OUT(Front L/R), SW(20Hz)
(
b
As the input source, you can switch from DVD to other ones.)
4.Press [Z3]
5.Press [STANDBY]
w
ZONE3 POWER OFF
6.Press [AMP]
7.Press [PURE DIRECT]
e
PURE DIRECT
(Initialization & Amp assign ZONE2 &
SURROUND mode : Multi ch STEREO &
ZONE2 Volume -20dB)
8.Press [DVD] twice
r
DVD (Main Zone)
g.10
g.11
g.12
g.13
g.14
g.15
