Marathon TS 910 - 3.5 DIELECTRIC TESTING

TS 910 TRANSFER SWITCH
PM140 REV 2 14/01/23 6 Thomson Power Systems
REQUIREMENTS FOR UPSTREAM CIRCUIT PROTECTIVE DEVICES of this
manual for further details. Short circuit currents listed for Standard type ATS are
Withstand ratings. Short circuit currents listed for Service Entrance type ATS are
Interrupting ratings based on the ratings of the supplied utility service disconnect
circuit breaker utilized.
WARNING: Do not install the transfer switch on systems with higher available short
circuit current levels than listed below Failure to follow these instructions can
result in death, serious injury, or equipment damage.
MODEL ATS TYPE POLES
MAX
VOLTAGE
AMPERAGE
SHORT
CIRCUIT
CURRENT
1
TS912A0100A
STANDARD
2
240V
100A
10kA
TS912A0100B
SERVICE
ENTRANCE
2 240V 100A 10kA
TS912A0200A
STANDARD
2
240V
200A
10kA
TS912A0200B
SERVICE
ENTRANCE
2 240V 200A 10kA
TS912A0400A
STANDARD
2
240V
400A
25kA
TS912A0400B
SERVICE
ENTRANCE
2 240V 400A 25kA
TS913A0100A STANDARD 3 240V 100A 22kA
TS913A0100B
SERVICE
ENTRANCE
3 240V 100A 10kA
TS913A0200A STANDARD 3 240V 200A 25kA
TS913A0200B
SERVICE
ENTRANCE
3 240V 200A 10kA
TS913A0400A STANDARD 3 240V 400A 50kA
TS913A0400B
SERVICE
ENTRANCE
3 240V 400A 25kA
1
AMPS RMS Symmetrical
3.5 DIELECTRIC TESTING
Do not perform any high voltage dielectric testing on the transfer switch with the TSC
9 controller connected into the circuit as serious damage will occur to the controller.
The control circuit isolation plug connected to the TSC 9 must be removed if high
voltage dielectric testing is performed on the transfer switch.
