TS 910 TRANSFER SWITCH
PM140 REV 2 14/01/23 22 Thomson Power Systems
14 FRONT INTERIOR VIEW (400A STANDARD ATS)
(3 Pole Model shown)
UTILITY SUPPLY
GEN SUPPLY
(TOP LUGS)
TSC 9
CONTROLLER
LOAD
(BOTTOM LUGS)
CUSTOMER
CONTROL
CONNECTIONS:
•GEN START
•LOAD SHED
•ALARM
•REMOTE TEST
TRANSFER
MECHANISM
ENCLOSURE
MOUNTING
HOLES (TYP 4)
