TS 910 TRANSFER SWITCH
PM140 REV 2 14/01/23 10 Thomson Power Systems
4.2 TS 910 OPTIONAL ACCESSORIES
The following optional accessories may be ordered as field installable kits.
Model Code
Description
TS910-HTR
Enclosure Heater, 120VAC Fused, supplied from ATS
Load Bus
TS910-SPD1PH
Surge Protective Device, Single Phase Class 1,
120/240V
TS910-SPD3PH
Surge Protective Device, Three Phase Class 1,
120/208V
TS910-KWLS1PH2
kW Load Shed Control output contact, Single Phase,
One Stage, 0-200A Current Transformers connected to
ATS Load Bus
TS910-KWLS1PH4
kW Load Shed Control output contact, Single Phase,
One Stage, 0-400A Current Transformers connected to
ATS Load Bus
TS910-KWLS3PH2
kW Load Shed Control output contact, Three Phase,
One Stage, 0-200A Current Transformers connected to
ATS Load Bus
TS910-KWLS3PH4
kW Load Shed Control output contact, Three Phase,
One Stage, 0-400A Current Transformers connected to
ATS Load Bus
TS910-WMS
Wireless Remote Alarm Messaging Module
TS910-N3R100A
TS910-N3R100B
TS910-N3R200A
TS910-N3R200B
TS913-N3R200A
TS913-N3R200B
TS910-N3R400A
TS910-N3R400B
NEMA 3R Door, External Door Mountable to NEMA 1
ATS Enclosure (Specify matching ATS model number)
TS910-UGI
Universal Generator Interface Start Kit
Additional information on TS 910 optional accessories can be obtained from our Website
(
www.thomsontechnology.com).
4.3 TYPICAL COMMISSIONING PROCEDURES
CAUTION:
Commissioning procedures must be performed by qualified
personnel only.
Note: The TYPICAL AUTOMATIC TRANSFER SWITCH COMMISSIONING PROCEDURES
MODEL SERIES TS 910 (attached as “Appendix A”) is provided for general information only
