Marathon TS 910 - 16 ENCLOSURE DIMENSIONS;CABLE TERMINALS

TS 910 TRANSFER SWITCH
PM140 REV 2 14/01/23 24 Thomson Power Systems
16 ENCLOSURE DIMENSIONS/CABLE TERMINALS
MODEL
ATS TYPE
POLES
MAX
VOLTAGE
AMPERAGE
DIMENSIONS
1
SHIPPING
WEIGHT
LBS
TERMINAL RATING
2
HEIGHT
WIDTH
DEPTH
QTY
PER
PHASE
RANGE
INCHES
INCHES
INCHES
TS912A0100A STANDARD 2 240V 100A 16 1/8" 18 7/8" 8 1/4" 20 lbs 1 #14 - 1/0
TS912A0100B
SERVICE
ENTRANCE
2 240V 100A 27 1/8" 18 7/8" 8 1/4" 30 lbs 1 #14 - 1/0
TS912A0200A STANDARD 2 240V 200A 27 1/8" 18 7/8" 8 1/4" 30 lbs 1
#6 -
250mcm
TS912A0200B
SERVICE
ENTRANCE
2 240V 200A 32 7/8" 18 7/8" 8 1/4" 35 lbs 1
#6 -
250mcm
TS912A0400A STANDARD 2 240V 400A 45 1/8" 24 7/8" 11" 70 lbs 2
#6 -
250mcm
TS912A0400B
SERVICE
ENTRANCE
2 240V 400A 45 1/8" 24 7/8" 11" 80 lbs 2
#6 -
250mcm
TS913A0100A STANDARD 3 240V 100A 16 1/8" 18 7/8" 8 1/4" 25 lbs 1 #14 - 1/0
TS913A0100B
SERVICE
ENTRANCE
3 240V 100A 27 1/8" 18 7/8" 8 1/4" 35 lbs 1 #14 - 1/0
TS913A0200A STANDARD 3 240V 200A 32 7/8" 18 7/8" 8 1/4" 35 lbs 1
#6 -
250mcm
TS913A0200B
SERVICE
ENTRANCE
3 240V 200A 32 7/8" 18 7/8" 8 1/4" 40 lbs 1
#6 -
250mcm
TS913A0400A STANDARD 3 240V 400A 45 1/8" 24 7/8" 11" 80 lbs 2
#6 -
250mcm
TS913A0400B
SERVICE
ENTRANCE
3 240V 400A 45 1/8" 24 7/8" 11" 90 lbs 2
#6 -
250mcm
1. Enclosure Dimensions are for reference (DO NOT USE FOR CONSTRUCTION.)
2. All cable connections are situable for Copper or Aluminium.
