Marathon TS 910 - 17.1 100 A, 2 P TRANSFER SWITCH UPSTREAM CIRCUIT PROTECTIVE DEVICES; 17.2 100 A, 3 P TRANSFER SWITCH UPSTREAM CIRCUIT PROTECTIVE DEVICES

TS 910 TRANSFER SWITCH
PM140 REV 2 14/01/23 26 Thomson Power Systems
17.1 100A, 2P TRANSFER SWITCH UPSTREAM CIRCUIT PROTECTIVE DEVICES
100A, 2 Pole transfer switches are suitable for use on circuits capable of delivering 10,000
Amps (RMS symmetrical), 240V when protected by the following upstream circuit breakers:
Manufacturer
Catalog Number
EATON/
CUTLER
HAMMER
FCL, FB, QCHW, GB, GHB, GC, GHC, GD, EHD,
FDB, FD,HFD, FDC, CA, CAH
SQUARE D
FI, FC, FA, FH, QOM1, QOM1-VH, Q2, Q2-H,
QOM2, QOM2-VH, QB, QD, QG, GJ
SIEMENS
CED6, D2, ED4, ED6, HED4, HED6, QP(Q2125),
QPH(QH2125H), QJ2, QJH2
GE
THQB, THQC, THHQB, THHQC, THHQL, TQDL,
THQDL, TQD, THQD, THED
17.2 100A, 3P TRANSFER SWITCH UPSTREAM CIRCUIT PROTECTIVE DEVICES
100A, 3 Pole transfer switches are suitable for use on circuits capable of delivering 22,000
Amps (RMS symmetrical), 240V when protected by the following upstream circuit breakers:
Manufacturer
Catalog Number
ABB
T1, T2, T3
EATON/
CUTLER
HAMMER
FB, FCL, GB, GC, GD, GHB, GHC, HBAX, QBHW,
QCHW, QHCX, QHPX, QPHW, EGB, EGE, EGH,
EGS, CAH, ED, EDB, EDC, EDH, EDS, FD, FDC,
FDCE, FDE, HCA, HFD, HFDE
GE FB, FC, TB1, TEY, THHQB, THHQC, THHQL, SEH,
SEL, SEP, THED, TFJ, TFK, THFK, THLC2, THQD
SQUARE D FA, FC, FH, FI, GJL, QO-VH, EDB, EGB, EJB, HD,
HG, HJ, HL, QOB-VH, Q2-H, QD, QG, QJ
SIEMENS BQD, BQD6, BQH, CQD, HBL, HBQ, BLH, CED6,
ED4, ED6, HED4, HHED6, HED6, HEG/HEB, HQP,
HCPP, NEG/NEB, NGB, NGG, QPH, QPPH, HDG,
LDG, NDG, HQJ2, HQJ2-H, QJ2H, QJH2
Note: 100A Service Entrance Rated TS 910 Transfer switches have an Interrupting Rating
on the Utility supply of 10,000 Amps (RMS symmetrical).
