Mark-10 ESM301 User Manual

Model ESM301 / ESM301L Test Stand User’s Guide
16
Label Description
+ or –
Increases or decreases the value.
ENTR
Returns to the Test Feature Setup menu
ESC
Exits the feature without saving changes
4.13 Units of Speed (UNITS)
This setting corresponds to units of speed measurement.
Default setting: in/min
Available settings: in/min, mm/min
Label Description
+ or –
Cycles through the available settings
ENTR
Returns to the Test Feature Setup menu
ESC
Exits the feature without saving changes
4.14 Programmable Button Function (KEYS)
Three button function modes are available:
1. Maintained
The crosshead will move continuously once the button has been pressed and held.
Subsequently pressing STOP will stop crosshead motion.
2. Momentary
The crosshead will move only if the button is held down. Releasing the button will stop
movement immediately.
3. Auto
Holding down the button for more than 0.5 seconds will enter momentary mode, at which time
an audible indicator will sound and the LED indicator on the button pushed will be illuminated.
A short tap on the button will operate the test stand in maintained mode. Pressing STOP
during maintained mode will stop crosshead motion.
Default setting: maintained
Available settings: maintained, momentary, auto
Label Description
+ or –
Cycles through the available settings
ENTR
Returns to the Test Feature Setup menu
ESC
Exits the feature without saving changes
S T O P & P A R : 8 - 1 n
E S C − + E N T R
U N I T S : i n /
m
i n
E S C − + E N T R
K E Y S : M A I N T A I N E D
E S C − + E N T R
