Model ESM301 / ESM301L Test Stand User’s Guide
19
1. Basic & Auto Return Modes (travel indication option not installed):
2. Basic & Auto Return Modes (travel indication option installed):
3. Cycling Mode (travel indication option not installed):
Note:
The min and max keys will not appear when a password has been set.
4. PC Mode
Appears the same as in Basic and Auto Return modes.
Label Description
menu
Enters Test Feature Setup
min
Sets speed to minimum speed. Will not appear when a
password has been set.
max
Sets speed to maximum speed. Will not appear when a
password has been set.
set
Sets speed to the programmed SPEED, UP SPEED, or
DN SPEED setting
Pressing menu will enter Test Feature Setup. If a password has been programmed, the display
will prompt the following:
The password is a four digit number. Press + or to increment or decrement the number. Once
the complete password has been entered, press ENTR. If correct, the display will enter the Test
Feature Setup menu. If the password is incorrect, the display flashes “INCORRECT
PASSWORD”, and then reverts to Operating Mode.
5.3 Basic Mode
The crosshead moves upward when UP is pressed, and downward when DOWN is pressed. When the
crosshead is in motion, an LED indicator on the button pushed will be illuminated. The KEYS setting
controls how crosshead movement responds to the push of the UP and DOWN buttons. The three
settings are:
S P E E D : 0 . 0 0
me n u m i n ma x S E T
1 . 2 7 5 0 . 0 0
me n u m i n ma x S E T
C Y C L E S
:
0 0 0 2 4
m
e n u
m
i n
m
a x S E T
P A S S
W
O R D 0 0 0 0
E S C + E N T R
TRAVEL
SPEED
TRAVEL
CYCLES REMAINING
