Marksman X4 - Anti-Car Jacking Operation

11
Plug-In Ports (continued)
P3 Sensor
2-Stage Sensor:
Allows easy connection with quick disconnect ability for
other optional devices.
1. Red: +12 Volt Constant Input
2. Black: Main Sensor Ground
3. Blue: Instant Trigger (-) Input
4. Green: Warn Away (-) Input
P1 Status LED Indicator
P2 Valet Switch
