Sensor
P5 Transceiver/Antenna
Black Wire No Connection
Red Wire No Connection
DBI Conection Harness (supplied)
P4 Data Adapter Communication
Data Interface Harness:
Allows direct communication between Marksman Remote Start and the vehicle’s data bus communication.
(Data Interface Modules sold separately)
Note: The DBI Connection Harness provides power and ground to the Data Interface Module. Do not connect
power and ground from Data Interface Module Harness.
