HC2 5 Pin Power Harness
Black/White (-) Dome Light Supervision Output
Black Chassis Ground
Yellow +12VDC Ignition Input
Open Provides +12VDC for Relay Connection
Red +12VDC Battery Input
HC4 10-Pin Main Harness
Open Provides +12VDC Relay Coil Power
Light Brown (-) Horn Output
Green (-) Common Door Pin Input
Violet (+) Common Door Pin Input
Blue (-) Hood / Trunk / Auxiliary Trigger Input
Red/White
(-) 300mA Programmable Channel 3 (Trunk) Output
White (+/-) Parking Light Relay Output
Brown (+) Siren Output
Violet/Black (-) 200mA Programmable Channel 4 Ouptut
White/Red (+/-) Parking Light Relay Input
H1 2-Pin Starter Disable Harness
Open Provides +12VDC Ignition Key On Power
Orange Provides “Ground-When-Armed” Output
HC3 3-Pin Door Lock Harness
Green (-) Lock
Light Blue Programmable Output (2nd Unlock Default)
Blue (-) Unlock
3
Wiring Harness Quick Reference
