Martin MAC Quantum Wash - DMX protocol; Basic mode

18 MAC Quantum Wash User Guide
DMX protocol
Basic mode
MAC Quantum Wash firmware version 2.0.0.
Channel DMX Value Percent Function
Fade
type
Default
value
1
0 - 19
20 - 49
50 - 200
201 - 210
211 - 255
0 - 7
8 - 19
20 - 78
79 - 82
82 - 100
Strobe/shutter effect
Shutter closed
Shutter open
Strobe, slow → fast
Shutter open
Random strobe, slow → fast
Snap 30
2
0 - 65535 0 - 100
Dimmer fade (MSB)
Closed → open
Fade 0
3
Dimmer fade, fine (LSB) Fade 0
4
0 - 65535 0 - 100
Red (MSB)
0 → 100%
Fade 0
5
Red, fine (LSB) Fade 0
6
0 - 65535 0 - 100
Green (MSB)
0 → 100%
Fade 0
7
Green, fine (LSB) Fade 0
8
0 - 65535 0 - 100
Blue (MSB)
0 → 100%
Fade 0
9
Blue, fine (LSB) Fade 0
10
0 - 10
11 - 171
171 - 255
0 - 4
4- 67
67 - 100
CTC
Disabled
Color temp. from 2000 K to 10 000 K in 50 K steps (see Table 4 on page
29)
10 000 K
Fade 101
Table 1: DMX Protocol - Basic mode
