Martin MAC Quantum Wash - Extended mode

22 MAC Quantum Wash User Guide
Extended mode
MAC Quantum Wash firmware version 2.0.0.
Channel DMX Value Percent Function
Fade
type
Default
value
1
0 - 19
20 - 49
50 - 200
201 - 210
211 - 255
0 - 7
8 - 19
20 - 78
79 - 82
82 - 100
Strobe/shutter effect
Shutter closed
Shutter open
Strobe, slow → fast
Shutter open
Random strobe, slow → fast
Snap 30
2
0 - 65535 0 - 100
Dimmer fade (MSB)
Closed → open
Fade 0
3
Dimmer fade, fine (LSB) Fade 0
4
0 - 10
11 - 171
171 - 255
0 - 4
4- 67
67 - 100
CTC
Disabled
Color temp. from 2000 K to 10 000 K in 50 K steps (see Table 4 on page
29)
10 000 K
Fade 101
5
0 - 10
11 - 12
13 - 14
15 - 16
17 - 18
19 - 20
21 - 22
23 - 24
25 - 26
27 - 28
29 - 30
31 - 32
33 - 34
35 - 36
37 - 38
39 - 40
41 - 42
43 - 44
45 - 46
47 - 48
49 - 50
51 - 52
53 - 54
55 - 56
57 - 58
59 - 60
61 - 62
63 - 64
65 - 66
67 - 68
69 - 70
71 - 72
73 - 74
75 - 76
77 - 78
79 - 80
81 - 82
0 - 4
4 - 5
5
6
7
7 - 8
8 - 9
9
10
11
11 - 12
12 - 13
13
14
14 - 15
15 - 16
16
17
18
18 - 19
19 - 20
20
21
21 - 22
22 - 23
23
24
25
25 - 26
26 - 27
27
28
29
29 - 30
30
31
32
‘Color wheel’ color selection effect
Open. RGB color mixing enabled
Color 1 - LEE 790 - Moroccan pink
Color 2- LEE 157 - Pink
Color 3 - LEE 332 - Special rose pink
Color 4 - LEE 328 - Follies pink
Color 5 - LEE 345 - Fuchsia pink
Color 6 - LEE 194 - Surprise pink
Color 7 - LEE 181 - Congo Blue
Color 8 - LEE 071 - Tokyo Blue
Color 9 - LEE 120 - Deep Blue
Color 10 - LEE 079 - Just Blue
Color 11 - LEE 132 - Medium Blue
Color 12 - LEE 200 - Double CT Blue
Color 13 - LEE 161 - Slate Blue
Color 14 - LEE 201 - Full CT Blue
Color 15 - LEE 202 - Half CT Blue
Color 16 - LEE 117 - Steel Blue
Color 17 - LEE 353 - Lighter Blue
Color 18 - LEE 118 - Light Blue
Color 19 - LEE 116 - Medium Blue Green
Color 20 - LEE 124 - Dark Green
Color 21 - LEE 139 - Primary Green
Color 22 - LEE 089 - Moss Green
Color 23 - LEE 122 - Fern Green
Color 24 - LEE 738 - JAS Green
Color 25 - LEE 088 - Lime Green
Color 26 - LEE 100 - Spring Yellow
Color 27 - LEE 104 - Deep Amber
Color 28 - LEE 179 - Chrome Orange
Color 29 - LEE 105 - Orange
Color 30 - LEE 021 - Gold Amber
Color 31 - LEE 778 - Millennium Gold
Color 32 - LEE 135 - Deep Golden Amber
Color 33 - LEE 164 - Flame Red
Color 34 - Magenta
Color 35 - Medium Lavender
Color 36 - White
Snap 0
Table 2: DMX Protocol - Extended mode
