32 MAC Quantum Wash User Guide
* Menus marked * are available only when the fixture is connected to mains power. All other menus are available in mains- and
battery-powered operation.
TEST*
TEST ALL
Run test sequence of all functions
To test a specific function, se Up/Down
buttons to scroll through functions and
pause. Press Enter to restart test
sequence.
Press Menu button to exit test
TEST LEDS
Run test sequence of LEDs only.
To test a specific LED group, se Up/Down
buttons to scroll through groups and
pause. Press Enter to restart test
sequence.
Press Menu button to exit test
TEST EFFECTS
ZOOM
Run test sequence of zoom functions.
Press Menu button to stop test
BEAM TWISTER
Run test sequence of Beam Twister
functions. Press Menu button to stop test
TEST PAN/TILT
PA N
Run test sequence of pan functions. Press
Menu button to stop test
TILT
Run test sequence of tilt functions. Press
Menu button to stop test
MANUAL
CONTROL*
EXTENDED
MODE
BASIC MODE
RESET RESET Reset fixture
STROBE ... AURA
BLUE
STROBE -- CONTROL
Scroll through effects to manually control
an effect
SERVICE
ERROR LIST Empty or up to 20 errors Display any errors in memory
FAN CLEAN ON/OFF Activate fan cleaning
ADJUST
PA N /T ILT AT EN D
STOP
STEP 1
To adjust, move head to P/T adjustment
position, then press Enter
STEP 2
To adjust, move head to P/T adjustment
position again, then press Enter
BEAM TWISTER ZERO POS For use by Martin Service or its authorized
agents only – use without Martin Service
documentation may cause damage
BEAM TWISTER FINE
PT FEEDBACK
ON
Enable pan/tilt position feedback
systems
OFF Disable pan/tilt position feedback
CALIBRATION
ZOOM 0.00 ...+/- xx% Define zoom home position
PAN 0.00 ...+/- xx% Define pan home position
TILT 0.00 ...+/- xx% Define tilt home position
LOAD DEFAULTS LOAD Load factory default calibration settings
SAVE DEFAULTS SAVE
Replace factory default calibration settings
with current calibration settings
USB
NO DEVICE
No USB device present or no firmware on
USB device
UPDATING FILES
Fixture updating internal memory from
USB device
AVAILABLE
FIRMWARE
XX.XX.XX ...
XX.XX.XX
Select firmware from versions stored in
internal memory. Scroll to select version,
then press Enter and confirm your choice
to update
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Notes (Default settings in bold print)
Table 5: Control menus
