32 MAC Viper Profile User Guide
INFORMATION
POWER ON TIME
TOTAL 0 ... XXX HR
Display hours fixture has been powered on
since manufacture (not user-resettable)
RESETTABLE
CLEAR
COUNTER?
YES/NO
Display hours fixture has been powered on
since last counter reset (user-resettable)
LAMP ON TIME
TOTAL 0 ... XXX HR
Display hours of lamp use since
manufacture
(not user-resettable)
RESETTABLE
CLEAR
COUNTER?
YES/NO
Display hours of lamp use since last
counter reset (user-resettable)
LAMP STRIKES
TOTAL 0 ... XXX HR
Display number of times lamp has been
struck since manufacture (not
user-resettable)
RESETTABLE
CLEAR
COUNTER?
YES/NO
Display number of times lamp has been
struck since last counter reset
(user-resettable)
SW VERSION* XX.XX.XX Displays currently active software version
SERIAL
NUMBER*
(XX)XXXXXXXXXXXX Displays fixture’s serial number
RDM UID* 4D50.XXXXXXXX Displays fixture’s unique RDM ID
FAN SPEEDS*
LAMPFAN L ...
BASEFAN 4
0 - XXX RPM
Displays current speed of all cooling fans
(lamp, head and base)
TEMPERA-
TURES*
ZOOM/FOCUS ...
BALLAST
X C
Displays temperature in °C of all PCBs and
of ballast capacitor
DMX LIVE*
RATE 0 - 44 HZ
DMX transmission speed in packets per
second
QUALITY 0 - 100% Percent of packets received
START CODE 0 - 255 Value of the DMX start code
STROBE/SHUTTER ... FX SYNC
Value received on each DMX channel
(values for fine control channels can only
be viewed if available in the DMX mode
the fixture is set to)
TEST*
TEST ALL
Run test sequence of all functions. Press
Escape button to stop test
TEST PAN/TILT
Run test sequence of pan and tilt
functions. Press Escape button to stop test
TEST EFFECTS
Run test sequence of all effects. Press
Escape button to stop test
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Notes (Default settings in bold print)
Table 2: Control menus
