Martin MAC Viper Profile User Manual

Control panel menus 33
MANUAL
CONTROL*
RESET RESET Click jog wheel to reset fixture
LAMP ON/OFF Manually strike/douse lamp
STROBE/
SHUTTER
0 - 255 Set shutter/strobe effect (default = 30)
DIMMER 0 - 255 Set dimmer opening
DIMMER FINE 0 - 255 Set dimmer opening, fine (LSB)
CYAN 0 - 255 Add cyan
MAGENTA 0 - 255 Add magenta
YELLOW 0 - 255 Add yellow
CTC 0 - 255
Adjust color temperature control (add
warmth)
COLOR WHEEL 0 - 255 Select color filter
GOBO W 1 SEL 0 - 255 Select gobo, breakup wheel (wheel 1)
GOBO W 1 I/R 0 - 255
Adjust gobo indexing/rotation, breakup
wheel (wheel 1)
GOBO W 1 I/R
FINE
0 - 255
Adjust gobo indexing/rotation, fine (LSB),
breakup wheel (wheel 1)
GOBO W 2 SEL 0 - 255 Select gobo, aerial wheel (wheel 2)
GOBO W 2 I/R 0 - 255
Adjust gobo indexing/rotation, aerial wheel
(wheel 2)
GOBO W 2 I/R
FINE
0 - 255
Adjust gobo indexing/rotation, fine (LSB),
aerial wheel (wheel 2)
EFFECTS WHEEL 0 - 255 Set FX wheel indexed position
EFFECTS SPEED 0 - 255 Set FX wheel movement speed
FROST 0 - 255 Set gobo animation wheel indexing
PRISM I/R 0 - 255 Set prism indexing/rotation
PRISM INX 0 - 255 Set prism indexed position
IRIS 0 - 255 Set iris aperture
ZOOM 0 - 255 Set zoom (default = 128)
ZOOM FINE 0 - 255 Set zoom, fine (LSB, default = 128)
FOCUS 0 - 255 Set focus
FOCUS FINE 0 - 255 Set focus, fine (LSB, default = 128)
PAN 0 - 255 Set pan angle (default = 128)
PAN FINE 0 - 255 Set pan angle, fine (LSB, default = 128)
TILT 0 - 255 Set tilt angle (default = 128)
TILT FINE 0 - 255 Set tilt angle, fine (LSB, default = 128)
FX 1
0 - 255 Select FX 1
FX 1 ADJUST 0 - 255 Adjust FX 1
FX 2 0 - 255 Select FX 2
FX 2 ADJUST 0 - 255 Adjust FX 2
FX SYNC 0 - 255 Set FX Sync
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Notes (Default settings in bold print)
Table 2: Control menus
