MARUTI SUZUKI CELERIO - Engine Oil Dipstick; Oil Level Check; Refilling

7-7
INSPECTION AND MAINTENANCE
76MH1-74E
Oil Level Check
76MM07003
(1) Engine oil dipstick
It is important to keep the engine oil at the
correct level for proper lubrication of your
vehicle’s engine. Check the oil level with
the vehicle on a level surface. The oil level
indication may be inaccurate if the vehicle
is on a slope. The oil level should be
checked either before starting the engine
or at least 5 minutes after stopping the
engine.
The handle of the engine oil dipstick is col-
ored yellow for easy identification.
52D084
Pull out the oil dipstick, wipe oil off with a
clean cloth, insert the dipstick all the way
into the engine, then remove it again. The
oil on the stick should be between the
upper and lower limits shown on the stick.
If the oil level indication is near the lower
limit, add enough oil to raise the level to
the upper limit.
Refilling
81A147
Remove the oil filler cap and pour oil
slowly through the filler hole to bring the oil
level to the upper limit on the dipstick. Be
careful not to overfill. Too much oil is
almost as bad as too little oil. After refilling,
start the engine and allow it to idle for
about a minute. Stop the engine, wait
about 5 minutes and check the oil level
again.
(1)
EXAMPLE
NOTICE
Failure to check the oil level regularly
could lead to serious engine trouble
due to insufficient oil.
EXAMPLE
Upper
Lower
ENGINE
OIL
CloseOpen
EXAMPLE
