MARUTI SUZUKI CELERIO - License Plate Light

7-26
INSPECTION AND MAINTENANCE
76MH1-74E
or the reversing light (5) from the light
housing, turn the holder counterclock-
wise and pull it out.
76MH0A123
(6) Removal
(7) Install
3) To remove the bulb of the tail/brake
light (3), the turn signal light (4) or the
reversing light (5) from bulb holder,
push in the bulb and turn it counter-
clockwise. To install a new bulb, push it
in and turn it clockwise.
76MH0A124
NOTE:
When reinstalling the light housing, make
sure the clips are properly attached.
License Plate Light
76MH0A125
1) Turn the cover (1) counterclockwise to
remove it.
76MH0A126
2) To remove and install the bulb of the
license plate light (2), simply pull out or
push in the bulb.
(3) / (4) / (5)
(6)
(7)
EXAMPLE
EXAMPLE
(1)
EXAMPLE
(2)
EXAMPLE
