MARUTI SUZUKI CELERIO - Halogen Headlights; Headlights; Side Turn Signal Light

7-23
INSPECTION AND MAINTENANCE
76MH1-74E
Headlights
Halogen headlights (1)
76MH0A112
76MH0A113
1) Open the engine hood. Disconnect the
coupler (2). Remove the sealing rubber
(3).
76MH0A114
2) Push the retaining spring (4) forward
and unhook it. Then remove the bulb
(5). Install a new bulb in the reverse
order of removal.
76MH0A115
NOTE:
You can see the position of retaining spring
from the hole of headlight.
Side Turn Signal Light (if equipped)
76MH0A006
1) Remove the light housing (1) by sliding
to left with your finger.
76MH0A007
2) Turn the bulb holder (2) clockwise and
pull it out from the light housing.
(1)
EXAMPLE
(3)
(2)
EXAMPLE
(4)
(5)
EXAMPLE
EXAMPLE
(1)
EXAMPLE
(2)
EXAMPLE
