MARUTI SUZUKI CELERIO - Fuel Gauge and Warning Lights

2-34
BEFORE DRIVING
76MH1-74E
Speedometer
The speedometer indicates vehicle speed.
Tachometer (if equipped)
The tachometer indicates engine speed in
revolutions per minute.
Fuel Gauge
With tachometer
76MH0A037
Without tachometer
76MH0A038
When the ignition switch is in the “ON”
position, this gauge gives an approximate
indication of the amount of fuel in the fuel
tank. “F” stands for full and “E” stands for
empty.
If the fuel meter indicator shows only one
segment to “E”, refill the tank as soon as
possible.
NOTE:
If the last segment blinks, it means that the
fuel is almost empty.
If the low fuel warning light (1) comes on,
fill the fuel tank immediately.
NOTE:
The activation point of the low fuel warning
light (1) varies depending on road condi-
tions (for example, slope or curve) and
driving conditions because of fuel moving
in the tank.
Refer to “Low Fuel Warning Light” in
“Warning and Indicator Lights” in this sec-
tion for details.
The mark (2) indicates that the fuel filler
door is located on the left side of the vehi-
cle.
NOTICE
Never drive the vehicle with the
engine revving in the red zone, or
severe engine damage can result.
Keep the engine speed below the red
zone even when downshifting to a
lower gear position. Refer to “Down-
shifting maximum allowable speeds”
in the “OPERATING YOUR VEHICLE”
section.
(1)
(2)
EXAMPLE
(1)
(2)
EXAMPLE
