MARUTI SUZUKI CELERIO - For Windshield Wipers; Wiper Blades

7-28
INSPECTION AND MAINTENANCE
76MH1-74E
Wiper Blades
76MM07002
If the wiper blades become brittle or dam-
aged, or make streaks when wiping,
replace the wiper blades.
To install new wiper blades, follow the pro-
cedures below.
NOTE:
Some wiper blades may be different from
the ones described here depending on
vehicle specifications. If so, consult your
authorised Maruti Suzuki workshop for
proper replacement method.
For windshield wipers:
64MM07020
1) Hold the wiper arm away from the win-
dow.
68PH00750
2) Squeeze lock (1) towards wiper arm (2)
and remove the wiper frame from the
arm as shown.
3) Unlock the lock end of the wiper blade
and slide the blade out as shown.
NOTICE
To avoid scratching or breaking the
window, do not let the wiper arm
strike the window while replacing the
wiper blade.
EXAMPLE
EXAMPLE
(2)
(2)
(1)
(1)
EXAMPLE
