MARUTI SUZUKI CELERIO - Conditions of Front Air Bags Deployment; Driver’s Front Air Bag; Front Passenger’s Front Air Bag

2-28
BEFORE DRIVING
76MH1-74E
Driver’s front air bag
76MH0A033
Front passenger’s front air bag
(if equipped)
76MH0A034
The driver’s front air bag is located behind
the center pad of the steering wheel and
the front passenger’s front air bag is
located behind the passenger’s side of the
dashboard.
The words “SRS AIRBAG” are molded into
the air bag covers to identify the location of
the air bags.
58MS030
Please refer to the “Seat Belts and Child
Restraint Systems” section in this section
for details on securing your child.
Conditions of front air bags deployment
(inflation)
80J097
• Frontal crash with a fixed wall that does
not move or deform at more than about
25 km/h.
80J098E
• Strong impact equivalent to frontal crash
such as above at left and right angles of
about 30 degrees (1) or less from the
front of your vehicle.
EXAMPLE
EXAMPLE
WARNING
Do not install a rear-facing child
restraint in the front passenger’s
seat. If the passenger’s front air bag
inflates, a child in a rear-facing child
restraint could be killed or severely
injured. The back of a rear-facing
child restraint would be too close to
the inflating air bag.
EXAMPLE
EXAMPLE
(1)
(1)
EXAMPLE
