Maruyama B42L - Attaching Shoulder Harness;Strap; Before Operation; Oil and Fuel

Attaching Shoulder Harness/Strap
[B42, B42A]
Snap the Hook into the ring on the drive shaft. To detach
the Harness quickly from the Trimmer/Brushcutter, push
the Red-Button.
[B42L]
Snap the strap hook into the ring on the drive shaft.
To detach the strap quickly from the Brushcutter, pull
upward on the red band.
Before Operation
Oil and Fuel
— US-15 —
Gearcase
Blade Bolt
Stabilizer
Brushcutter Blade
Holding Tool
(3,5mm Pin)
Left-hand thread
Washer
Boss Adapter
WARNING
POTENTIAL HAZARD
• Without the Shoulder Harness/Strap
Installed on the Trimmer/Brushcutter,
the blade can produce side thrust which
can expose the operator and bystanders
to blade contact.
WHAT CAN HAPPEN
• Contact with Brushcutter blade can
cause severe personal injury.
HOW TO AVOID THE HAZARD
• Never operate the Trimmer/Brushcutter
without installing and using the
Shoulder Harness/Strap.
Red Button
PRESS
DANGER
POTENTIAL HAZARD
• In certain conditions gasoline is extreme-
ly flammable and highly explosive.
WHAT CAN HAPPEN
• A fire or explosion from gasoline can
burn you, others, and cause property
damage.
HOW TO AVOID THE HAZARD
• Use a funnel and fill the fuel tank out-
Red Band
Ring
Strap
