Masibus LC5296 DC User Manual

Model: LC5296 Dual Channel Temperature Controller
Doc. Ref. no.:- m61C/om/101
Issue no. 01D/ENGG-114
User’s Manual Page 14 of 30
PV
(Present
Value)
Display
PV1
 4 digital 0.56 inch RED Display
 Display parameter name when user
set parameter.
 Display Parameter Value when in
Edit mode. (For Single Display
Model Only)
 Display error message when an
error occurs.

PV 2
(Process
Value)
Display
PV2
 4 digital 0.56 inch RED
 Display process value for Input
2
 Display parameter value of
parameter in process value
field when user set parameter.

Relay-1
Indication
RL1
 ON when Relay-1 is energized &
OFF otherwise.

Relay-2
Indication
RL2
 ON when Relay-2 is energized &
OFF otherwise.

TX
Indication
Tx
 ON when device is transmitting
some Data (RS-485).

RX
Indication
Rx
 ON when device is receiving some
Data (RS-485).


Masibus LC5296 DC Specifications

General

Brand	Masibus
Model	LC5296 DC
Category	Controller
Language	English
