Model: LC5296 Dual Channel Temperature Controller
Doc. Ref. no.:- m61C/om/101
Issue no. 01D/ENGG-114
User’s Manual Page 20 of 30
6.4 Map Mode
NOTE:-
Please refer Table no.10.4 mapping options for Relay and Retransmission.
HY-2
(Hy-2)
Hysteresis 2
(For Relay-2)
Hysteresis Value (in °C) for Relay-2 during
ON-OFF type Control.
1 to 100
RTD Input
0.1 to 10.0
RTD.1 Input
1 to 100
Linear Input with DP=0
0.1 to 10.0
Linear Input with DP=1
0.01 to 1.00
Linear Input with DP=2
0.001 to
0.100
Linear Input with DP=3
5
PASS
(pass)
Password
Set Device Password
0 to 99
1
VERS
(vers)
Version
Shows the Version of the Current Firmware
-
MAP PARAMETERS
Parameter
(PV display)
Setting Name & Description
Default
Value
Show if Only
Symbol
Name
RL-1
(rL-1)
Map Relay-1
For mapping relay-1
IN 1
RL-2
(rL-2)
Map Relay-2
For mapping relay-2
IN 1
RT-1
(rt-1)
Map
retransmission-1
For mapping retransmission-1
IN 1
Device Supports
Retransmission
Output.
RT-2
(rt-2)
Map
retransmission-2
For mapping retransmission-2
IN 1
Device Supports Dual
Retransmission
Output.
