Masibus LC5296 DC User Manual

Model: LC5296 Dual Channel Temperature Controller
Doc. Ref. no.:- m61C/om/101
Issue no. 01D/ENGG-114
User’s Manual Page 21 of 30
6.5 Calibration Mode
NOTE:-
The retransmission output type is jumper selectable. Thus if current type or
voltage type output, will be decided by the position of the jumper.
No need to feed input while calibrating Rx. o/p. just make the value in
calibration mode equal to the displayed value.
CALIBRATION PARAMETERS
Parameter
(PV display)
Setting Name & Description
Default
Value
Show if Only
Symbol
Name
CZ-1
(CZ-1)
Calibration Zero-1
Calibration Zero for PV Input-1
(PV Display : Current PV)
-
CS-1
(CS-1)
Calibration Span-1
Calibration Span for PV Input-1
(PV Display : Current PV)
-
CZ-2
(CZ-1)
Calibration Zero-2
Calibration Zero for PV Input-2
(PV Display : Current PV)
-
CS-2
(CS-2)
Calibration Span-2
Calibration Span for PV Input-2
(PV Display : Current PV)
-
RTZ1
(rtz1)
Retransmission
Zero-1
Calibration Zero for
Retransmission Output-1
(SV Display : If voltage: 0.000
If Current: 4.000)
-
Device Supports
Retransmission
Output
RTS1
(rts1)
Retransmission
Span-1
Calibration Span for
Retransmission Output-1
(SV Display : If voltage: 8.000
If Current: 20.00)
-
Device Supports
Retransmission
Output
RTZ2
(rtz2)
Retransmission
Zero-2
Calibration Zero for
Retransmission Output 2
(SV Display : If voltage: 0.000
If Current: 4.000)
-
Device Supports
Dual
Retransmission
Output
RTS2
(rts2)
Retransmission
Span-2
Calibration Span for
Retransmission Output-2
(SV Display : If voltage: 8.000
If Current: 20.00)
-
Device supports
Dual
Retransmission
Output
