Masibus LC5296 DC User Manual

Model: LC5296 Dual Channel Temperature Controller
Doc. Ref. no.:- m61C/om/101
Issue no. 01D/ENGG-114
User’s Manual Page 16 of 30
6.1 Run Time Indication/Function
Following parameters can view or change during run time.
 In upper display, it shows Process value for input-1.
 In lower display, it shows Process value for input-2.
6.2 Set Point Setting
6.3 Configuration Mode
Parameter
(PV display)
Sett in g nam e and
desc ription
Default
valu e
Shows
only i f
Symbol
Name
ST-1
(st-1)
Set Point 1
Range Depending on PV
sensor type selected
10 0
-
ST-2
(st-2)
Set Point 2
Range Depending on PV
sensor type selected
20 0
-
Parameter
(PV display)
Setting Name & Description
Default
Value
Show if Only
Symbol
Name
INPT
(in 1)
INPUT Type
Set PV Input -1 Type
rtd.1 / rtd/ 0-5v / 1-5v
Value
Input Type
Range
7
RTD.1
-199.9 to 850.0 °C
8
RTD
-200 to 850 °C
9
0-5 V /
0-20 mA*
-1999 to 1999
10
1-5 V / 4-
20 mA*
*Use external 250ohms,0.1% for current
input
0-5V
ZERO
(zro.1)
Zero-1
Automatically change to the Input Lower
Range with changing of Input Type
(Refer Above Table)
Can be set to any value within the Input
Range & less the SPAN Value.
-1999
(If 0-5V)
SPN.2
(spn.2)
Span-1
Automatically change to the Input Higher
Range with changing of Input Type
(Refer Above Table)
Can be set to any value within the Input
Range & greater the ZERO Value.
9999
(If 0-5V )
