Masibus LC5296 DC User Manual

Model: LC5296 Dual Channel Temperature Controller
Doc. Ref. no.:- m61C/om/101
Issue no. 01D/ENGG-114
User’s Manual Page 17 of 30
IN 2
(1n 2)
Input-2 Type
Set PV Input -2 Type
rtd.1 / rtd/ 0-5v / 1-5v
Value
Input Type
Range
7
RTD.1
-199.9 to 850.0 °C
8
RTD
-200 to 850 °C
9
0-5 V /
0-20 mA*
-1999 to 1999
10
1-5 V / 4-
20 mA*
*Use external 250ohms,0.1% for current
input
0-5 V
Zro.2
(ZRo.2)
Zero-2
Automatically change to the Input Lower
Range with changing of Input Type
(Refer Above Table)
Can be set to any value within the Input
Range & less the SPAN Value.
-1999
(If 0-5 V)
SPN.2
(spn.2)
Span-2
Automatically change to the Input Higher
Range with changing of Input Type
(Refer Above Table)
Can be set to any value within the Input
Range & greater the ZERO Value.
9999
(If 0-5 V)
TSP1
(tsp1)
Type of
Set Point-1
Set Type of Set Point
l-on / H-on
0 : L-ON (Lower ON)
1 : H-ON (Higher ON)
Refer ON-OFF Control on Page:30
0
(L-ON)
TSP2
(tsp2)
Type of
Set Point-2
Set Type of Set Point
l-on / H-on
0 : L-ON (Lower ON)
1 : H-ON (Higher ON)
Refer ON-OFF Control on Page:30
0
(L-ON)
OPES
(opes)
OPEN Sensor
Status
Set Control O/P & Retransmission state
when Input OPEN condition.
down / up
0 : DOWN
1 : UP
Refer Page:35
0
(DOW
N)
DP 1
(dp 1)
Decimal Point
Set position of Decimal Point on Display.
0 / 0.0 / 0.00 / 0.000
0
