Masibus LC5296 DC User Manual

Model: LC5296 Dual Channel Temperature Controller
Doc. Ref. no.:- m61C/om/101
Issue no. 01D/ENGG-114
User’s Manual Page 26 of 30
11
Baud Rate
40011
Int
R + W
12
Relay Delay -1
40012
Int
R + W
13
Relay Delay -2
40013
Int
R + W
14
Retransmission o/p Type -1
40014
Int
R + W
15
Retransmission o/p Type -2
40015
NA
NA
16
Hysteresis 1
40016
Int
R + W
17
Hysteresis 2
40017
Int
R + W
18
Pass word
40018
Int
R + W
19
Set Value 1
40019
Int
R + W
20
Set Value 2
40020
Int
R + W
21
Input Type-2
40021
Int
R + W
22
Zero-2
40022
Int
R + W
23
Span-2
40023
Int
R + W
24
Decimal Point-2
40024
Int
R + W
25
Relay-1 Map
40025
Int
R + W
26
Relay-2 Map
40026
Int
R + W
27
Retransmission-1 Map
40027
Int
R + W
9.3 Exceptional Response
CODE
MEANING
01
Function code Invalid. It must be 01, 05, 03 or 06.The function code received in
the query is not allowable action for the slave.
02
Illegal address value. The data address received in the query is not an
allowable address for the salve.
03
Illegal data value. A value contained in the query data field is not an allowable
value for the salve.
06
When Master device write some parameters to Slave device, If slave device
busy then it will send 06 code to indicate slave device is busy.
TABLE – 8
Note: 1. Refer Menu Mode Description Table the value & Range of each
Parameter.
EX:
Input-1 Type (Applicable Range : 5 to 9):
Input-1 Type
Value
Rtd
5
Rtd.1
6
0 – 5V
7
1 – 5V
8
0 – 10V
9
Input-2 Type (Applicable Range : 5 to 8):
Input-1 Type
Value
Rtd
5
Rtd.1
6
0 – 5V
7
1 – 5V
8
