Masibus LC5296 DC User Manual

Model: LC5296 Dual Channel Temperature Controller
Doc. Ref. no.:- m61C/om/101
Issue no. 01D/ENGG-114
User’s Manual Page 7 of 30
Relay Output
Relays
2
Type
Single Change over
Three Terminals (C, NO, NC)
Rating
2A @ 230VAC / 30VDC
Retransmission Output
Number of output
1 / 2
Retransmission mapping
With respect to Input no.
Output Signal
4-20mA / 0-20mA /1-5VDC / 0-10V DC
Load resistance
 For Current o/p
 For Voltage o/p
< 500Ω.
> 3KΩ.
Output accuracy
±0.25% of span
Loop Power Supply
Supply Voltage
24VDC (±1V) @60mA with Inbuilt Short Circuit
Protection
2.4 Communication Details
Communication
Interface
RS485 (2 Wire)
Protocol
Modbus-RTU
Baud rate
9600, 19200, 38400 bps
2.5 Power Supply
Standard
85-265VAC/ 100-300VDC
Optional
18-36VDC
Power consumption
<10VA
Data backup
Non-volatile memory (can be written up to 100000 times)
Isolation (Withstanding voltage)
 Between primary terminals* and secondary terminals**:
At least 1500 V AC for 1 minute
 Between primary terminals* and grounding terminal:
At least 1500 V AC for 1 minute
 Between grounding terminal and secondary terminals**:
At least 1500 V AC for 1 minute
 Between secondary terminals**:
At least 500 V AC for 1 minute
* Primary terminals indicate power terminals and relay output terminals.
** Secondary terminals indicate analog I/O signal and Communication O/P.
Insulation resistance: 20MΩ or more at 500 V DC between power terminals and
grounding terminal.
