Model: LC5296-H / LC5296 / 5006-RN / 408-M / LC5248E
Doc. Ref. no.:- m61C/om/101
Issue no. 13
User’s Manual Page 21 of 36
10 to 100
SRNO
(srno)
Serial No.
Unit ID for Modbus-RS485 Communication
1 to 247
1
If Device
Supports
RS-485
Communica
tion
BAUD
(baud)
Baud Rate
Set Modbus RS485 Communication Baud
Rate
9600 / 19.2k / 38.4k
0 : 9600 (9600 bps)
1 : 19.2K (19200 bps)
2 : 38.4K (38400 bps)
0
(9600)
If Device
Supports
RS-485
Communica
tion
RD 1
(rd 1)
Relay Delay
(For Relay-1)
Relay Delay is amount of time (in sec), that
Relay 1 will wait before getting ON after
the ON condition occurs.
0 to 99 sec
1 sec
RD 2
(rd 2)
Relay Delay
(For Relay-2)
Relay Delay is amount of time (in sec), that
Relay 2 will wait before getting ON after
the ON condition occurs.
0 to 99 sec
1 sec
RT-1
(rt-1)
Retransmission
1 Type
Retransmission-1 Output Type
This output is according to PV input.
Zero & Span acts as Min & Max value of
retransmission o/p scale respectively.
0-5v / 1-5v / 0-10 / 4-20 / 0-20
0 : 0-5V
1 : 1-5V
2 : 0-10V
3 : 4-20mA
4 : 0-20mA
Voltage or Current is Jumper Selectable
from the Hardware.
0
(0-5V)
