Masibus LC5296-H - List of Accessories; Safety Precautions

Model: LC5296-H / LC5296 / 5006-RN / 408-M / LC5248E
Doc. Ref. no.:- m61C/om/101
Issue no. 13
User’s Manual Page 5 of 36
List of Accessories
The product is provided with the following accessories according to the model and
suffix codes (see the table below). Check that none of them are missing or damaged.
No
Item name
Part number
Qty
Remarks
1
Mounting Clamps
-
2
Safety Precautions
The product and the instruction manual describe important information to prevent
possible harm to users and damage to the property and to use the product safely.
Understand the following description (signs and symbols), read the text and
Observe Descriptions.
DESCRIPTION OF SIGN
Ordering Code
Model
Input
Auxiliary Power Supply
408-M
1
J
U1
85-265 VAC / 100-300 VDC
2
K
U2
18-36 VDC
3
T
4
R
5
S
6
Pt-100
C
4-20mA
D
0-20mA
E
1-5 V
F
0-5 V
G
0-10 V
