Model: LC5296-H / LC5296 / 5006-RN / 408-M / LC5248E
Doc. Ref. no.:- m61C/om/101
Issue no. 13
User’s Manual Page 6 of 36
2. SPECIFICATIONS
2.1 Inputs
Analog Input
Input Type
Thermocouple, RTD (Pt100), Current, Voltage
Display Range
Refer Table-2.1
Accuracy
+ (0.25% of Full Span + 1 degree) for T/C and RTD
input.
+ (0.1% of Full Span + 1 count) for Linear input.
ADC Resolution
16 bits
Display Resolution
0.1°C / 1 Count
Sampling Rate
5 Samples/Sec
CJC Error
±3.0 °C Max
Sensor open Detection
All inputs except 0-5V, 0-10V
Sensor Burnout current
0.25uA
RTD excitation current
0.166mA (Approx)
Allowable wiring resistance for
RTD
Maximum 15 ohms/wire (Conductor
resistance between three wires should be equal)
NMRR
> 40 dB
CMRR
> 120 dB
Temp-co
< 150ppm/°C
Input Impedance
> 1MΩ (Voltage Input)
250Ω (Current Input)
Max Voltage
20VDC
Input type
Range
PT100 (0.1ºC)
-199.9 to 850.0 ºC
PT100 (1ºC)
-200 to 850ºC
J
-199.9 to 1200ºC
K
-199.9 to 1372ºC
T
-199.9 to 400ºC
R
0 to 1768ºC
S
0 to 1768ºC
*4-20mA /1-5VDC,
*0-20mA /0-5VDC
-1999 to 9999
(Field Scalable)
0-10VDC
-1999 to 9999
(Field Scalable)
Table-2.1
*Use external 250ohms, 0.1% for current Input
