Page | 25
MINT – IO
REF NO: m25A/om/101
Issue No: 11
Invalid response for sent
request from slave to master
Count of timeout query for each
timeout
Connection of slave with
master is whether enable or
disable
Software version describes the current version of the master software,
whether it is working from personal pc or PLC or SCADA. Software type
shows the software is from PC, PLC or SCADA.
Part name: Part identity of slave, which is connected to the master software
or PLC.
If mINT CP is connected then part name should be MINT-CP-ET-000-0 in
32007 to 32018 addresses.
Com status: whether comport is enabled or disabled.
This can be analyzing from address 32019 to 32020 from CP registers.
Ethernet diagnostics
IP address: 4 bytes of IPv4 address can diagnosis from address 32023 to
32026, from most significant Byte to least significant Byte.
IP mask: 4 bytes of IPv4 address can diagnosis from address 32027 to
32030, from most significant Byte to least significant Byte.
TCP port: port address (502) for CP communication.
Station No:
No. of request: This swap long number describes sent queries from the
master CP to slave mINT IOs.
No. of valid request: This number shows the valid queries that responded by
the slave mINT IOs.
No. of invalid request: This number shows the no of queries that are not
qualified or do not have sufficient information, those are rejected (responded
as invalid) by the slave mINT IOs.
No. of Modbus Time-out: As per configure value of time out at address
45030 address, count of all timed out response can be derived from address
32039 and 32040 as higher and lower Byte respectively.
IO’s station status (32055): They show status of the slaves connected to the
master (mINT CP) whether it is enabled of disabled.
Second, min, hour, day, week day, month, and year of real time clack can
be observe at 32062 to 32068 addresses. Note: Current Model Not support
RTC clock
