4.OntheOdessamodels,lifttheglassretainersateachsideupandoutandlifttheglassclear.
5.Ontheothermodels,liftthefrontglassclear,beingcarefulnottodislodgethesideglasses.Then
lifteachsideglassclear.Thiswillrevealaglasssealingrope,abackingstripandaspringatthe
rearedgeofeachsideglass.
FasteningScrew
Spring
GlassRope
SideGlass
BackingStrip
6.AssemblyisthereverseoftheaboveforOdessamodels.Forallmodels,cleantheinsidesurfaces
oftheglassandkeepfingerprintsoffthemastheyareassembled.
7.ForBostonandSantaFemodels,firstassembleonesideglasstotheheater.Fitthespringfirst,
thenthebackingstrip,thentheropeandfinallytheglass.
8.Withonesideglassinplace,thefrontglasscanbefitted.Pressthesideglassbacktocompressits
springsothatthefrontglasscandropintoitsslot.
9.Holdthetwotopfrontcornersoftheglassestogetherwithapieceofstickytapetostopthem
fallingoutwards.
10.Fitthesecondsideglassasin6above.Onceitispressedbackintotherearslotitcanswingin
behindthefrontglassandthendropdownintoitsbottomslot.
11.Replacethetopglasstrim,fititsfasteningscrews,removethestickytape.
12.Forallmodels,refitthelouvre.
PILOTFLAMEADJUSTMENT(SantaFe(flueless)modelsarenotadjustable)
Ifthepilotflameaerationneedsadjustment,itcanbedonebyrotatingtheairentryadjustingsleeve
locatedabouthalfwayupthebarrelofthepilotburner,usingtheendofalongsmallscrewdriver.
Accessisgainedbyremovingtheglassandliftingthefrontlogclear(seeabove).
MAINBURNERREMOVAL
1.Removetheglass(seeabove).
2.Liftthelogsoutcarefully.
3.Removethepedestalrearcoverplate(orfan,iffitted).
4.Disconnectthefeedpipeatthemaininjector(brasselbow).
5.Unscrewthemaininjector.
6.Insidethefirebox,removetheairmeteringplate(justinfrontoftheburner–threescrews)andlift
outthedraughtdeflector.Removethefourburnerretainingscrews.
