Sheet1: Inspection and measurement table of appearance and protection parts common fault

S/N

Troubles Solutions

Check if the frame and supporting ear are deformed or broken. Do

appropriate repair and touch-up painting

Replace the plastic cover parts

Panel damaged in the

off-road driving

Re-paste the sticker and install the warning sign by rivets.

Check if the reducer box or differential in the front and rear bridge is

broken or oil leak.

Check if the bottom of the engine body is broken or oil leaks.

The frame bottom cover

damaged by the object

standing out from the

ground.

Replace new frame bottom cover.

Sheet2: checking methods, solution for common faults of Brake system.

S/N

Troubles Solutions

1. Check whether the parking brake operating lever has been restored

to the release position.

1. Check if the brake discs on the front and rear wheels are deformed

1 Locking brake system

1. Check the brake calipers on the front and rear wheels parts, if the

hydraulic cylinder is blocked, or install brake caliper parts are

deformed.
