SEAT

To remove the seat, pull the seat lock lever

upward and pull up the rear part of the seat.

1. Seat 2. Seat lock lever

To install the seat, insert the projections on

the front of the seat into the seat holders and

push down on the seat at the rear.

Make sure that the seat is securely fit led.

1. Seat holder（×2） 2. Projection（×2）

Storage box

The storage box is under the seat. If the

manuals or other documents need to be

stored in the box, make sure they are

wrapped with proper plastic bags. When

cleaning the ATV, avoid water inflowing into

the box.

4-18
