Sheet4: checking methods, solution for common faults of running system.

S/N

Troubles

Solutions

Check if the fastening nut which on the shift straight rod and steering

knuckle and steering stem is damaged or loosen.

Check if the rod of the shift straight rod is damaged.

Steering wheel gap is too

large

Check if the gear gap on the steering is too large.

Check if the bearing in the steering knuckle.

Check if the main ball stud is damaged.

Check if the fastening nut on the front wheel, front wheel axle is loosen

or damaged.

Check if the internal spline of front wheel rim, outer spline of the front

wheel axle is loosen or abrasion.

Front wheel shaking too

much when moving.

Check if the rubber spring ring which connecting the front suspension

and chassis is damaged.

Check if the bearing in the rear axle bearing seat is damaged.

Check if the moving bearing which connecting rear axle bearing seat

and swinging arm is abrasion or loosen.

Check if the fastening nut on the rear axle and rear wheel is loosen or

damaged.

Check if the internal spline of rear wheel rim, outer spline of the rear

wheel axle is loosen or abrasion.

Rear wheel shaking too

much when moving

Check if the rubber spring ring which connecting the rear suspension

and chassis is damaged.
