6. There are two modes to show the bar graph. You can observe the
fluctuation range of measured current. The first mode is
0-20-40-60-80-100, the second is 0-10-20-30-40.( Figure 5 and
Figure 6 )
( Figure 6. Maximum Value Of Current Measurements )
( Figure7. Current Exceeds 1000A )
